GE THQB21100ST1 Type THQB Molded Case Miniature Supplementary Protector, 120/240 VAC, 100 A, 10 kA Interrupt, 2 Poles, LI/Internal Common/Non-Interchangeable/Shunt Trip

Product Description

The GE THQB21100ST1 is a THQB molded case miniature supplementary protector with specifications designed for electrical distribution and control applications. This device operates on 120/240 VAC and has an amperage capacity of 100 A with a 10 kA interrupt rating. The design includes two poles.

• Compact and thermal magnetic design
• Suitable for reverse feed
• Quick-make quick-break mechanisms

Product Highlights

This breaker features a fixed instantaneous and fixed long-time trip function. It is ideal for use in residential and commercial settings, designed to provide reliable protection.

Product Information

Standard Information

• Brand: GE
• Manufacturer: General Electric

Technical Specifications

• MPN: THQB21100ST1
• GTIN: 00783164033632
• UPC: 783164033632
• Tripping Type: LI/Internal Common/Non-Interchangeable/Shunt
• Wire Size: 6 to 1/0 AWG
• Interrupt Rating: 10 kA
• Dimensions: 2 inches W x 2-3/8 inches D x 3-9/32 inches H
• Mounting Type: Bolted-On
• Poles: 2
• Voltage Rating: 120/240 VAC
• Amperage Rating: 100 A
• Application: Electrical Distribution and Control Applications
• Standards Compliance: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL File No. E11592
