GE THQB1140 THQB Molded Case Miniature Supplementary Protector, 120/240 VAC, 40 A, 10 kA Interrupt, 1 Pole

Product Description

The GE THQB1140 is a molded case miniature supplementary protector designed for use in residential and commercial applications. This device operates at 120/240 VAC, handles up to 40 amps, and features a 10 kA interrupt rating. The protector's thermal magnetic trip type ensures reliable operation, making it dependable for various electrical distribution needs.

• Amperage rating of 40 A
• Temperature rating of 40 degrees Celsius
• Compact design with dimensions of three point two eight inches in height, one inch in width, and two point three eight inches in depth

Product Highlights

This supplementary protector is ideal for bolting onto load centers and lighting panels. The quick-make, quick-break mechanisms provide additional safety and reliability.

Product Information

Standard Information

• Voltage Rating: 120/240 VAC
• Number of Poles: 1

Technical Specifications

• Type: Type THQB Molded Case Miniature
• Trip Type: LI/Thermal Magnetic
• Wire Size: 8 to 3 AWG
• Mounting Type: Bolted-On
• Interrupt Rating: 10 kA
• Weight: 17.607 lb
• Manufacturer: ABB Electrification
