GE THHQB2160 Q-Line Thermal Magnetic Circuit Breaker 120/240 VAC 60 A

Product Description

The GE Q-Line THHQB2160 Thermal Magnetic Molded Case Circuit Breaker is engineered for superior protection and ease of use, ideal for both residential and commercial settings. This 120/240 Vac, 60 A breaker features a dual-pole design and is rated for 22 kA interrupt.

• Quick-make/quick-break mechanisms enhance the safety and operational reliability.
• Bolt-on installation guarantees secure bus connections, suitable for load centers and lighting panels.
• Equipped with common trip bars and trip indication for immediate status assessment.

Product Highlights

This circuit breaker is compatible with auxiliary contact and shunt trip accessories and is designed to support HID applications. It is non-interchangeable trip with quick electrical connectivity options for both copper and aluminium wires.

Product Information

Technical Specifications

• Brand: General Electric
• MPN: THHQB2160
• Type: Thermal Magnetic
• Number of Poles: 2
• Voltage Rating: 120/240 VAC
• Amperage Rating: 60 A
• Interrupt Rating: 22 kA
• Wire Size: 8 to 3 AWG
• Temperature Rating: 40 degrees Celsius
• Mounting Type: Bolt-On
• Dimensions: 3-9/32 in H x 2 in W x 2-3/8 in D
• Standards and Approvals: UL E11592, HACR Rated
