GE TG3223 SWITCH SAF 240VAC 100A 2 POLES NEMA 1

Product Description

GE Spec-Setter TG3223 is a fusible general duty safety switch designed for use in residential and light commercial settings. Rated at two hundred forty volts alternating current with a maximum current of one hundred amperes, this safety switch provides crucial protection and controls electrical distribution. This model meets the standards set by UL and CSA for safety and reliability.

• Fusible general duty safety switch
• Rated for 240 VAC and 100 A
• Features a quick-make, quick-break mechanism

Product Highlights

Installed appropriately, this switch can serve as equipment protection and safety control for various applications.

Product Information

Standard Information

• Manufacturer: ABB Electrification
• Brand: GE

Technical Specifications

• MPN: TG3223
• Type: Fusible General Duty
• Voltage Rating: 240 VAC
• Amperage Rating: 100 A
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Dimensions: 21.33 inches H x 9.4 inches W x 4.9 inches D
• Material: Steel
• Temperature Rating: 60/75 deg C
• Short Circuit Current Rating: 100 kA
• Mounting Type: Surface
• Enclosure Type: NEMA 1
• Horsepower Rating: 7.5 hp Standard Fuse/15 hp Time Delay
