GE TEY360 BREAKER CKT PNL LTG 277/480VAC 60A 14KA

Product Description

The GE TEY360 is a circuit breaker designed for lighting panel applications with a voltage rating of two hundred seventy-seven to four hundred eighty volts AC. It has a current rating of sixty amps and an interrupt rating of fourteen kiloamps. This breaker operates on a three-pole system, making it suitable for a variety of electrical distribution needs.

• Voltage Rating: 277/480 VAC
• Amperage Rating: 60 A
• Interrupting Rating: 14 kA

Product Highlights

This circuit breaker features a compact design, quick-make quick-break mechanism, and common trip bars for reliable operation. It is UL listed and can be used in a range of industrial applications.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Type: Molded Case, Thermal Magnetic
• Frame: TEY
• Phase: 3
• Dimensions: 5-1/4 in H x 3 in W x 3-1/16 in D
• Mounting Type: Bolt-On
• Temperature Rating: 40 deg C
• Wire Size: 14 to 8 AWG, 12 to 8 AWG
• Connection Type: Load Lug
• Number of Poles: 3
