Ge NS18H24HA5(O) Connect Series Side-DischarGe Inverter Heat Pump 2-Ton

Product Description

The GE NS18H24HA5(O) 2-Ton Connect Series Side-Discharge Inverter Heat Pump offers climate control with R454B refrigerant, a low Global Warming Potential (GWP), eco-friendly option. Rated for heating down to -22°F and ENERGY STAR® certified, this heat pump delivers performance, even in extreme conditions. The ducted side-discharge configuration is ideal for limited space applications.

• Features R454B Refrigerant
• Provides Cold Climate Comfort
• Offers a Space Saving Solution

Product Highlights

This Connect Series heat pump is efficient, quiet, and space-saving, offering homeowners cost-effective year-round climate control.

Product Information

Standard Information

• Brand: GE
• Manufacturer Part Number: NS18H24HA5(O)

Technical Specifications

• Color Appearance: Gray
• Compressor Type: Inverter
• EER: 12 (when paired with NAM24V1TA5S)
• HSPF Rating: 10 (when paired with NAM24V1TA5S)
• Product Type: Heat Pump
• Refrigerant Type: R454B
• SEER: 18 (when paired with NAM24V1TA5S)
• SEER2: 18
• Series: Connect
• Style: Heat Pump
• Tonnage: 2
• Unit Type: Outdoor
• Cooling Rated Capacity BTU/Hr: 24000
• Overall Depth: 17.13"
• Overall Height: 30.13 in
• Overall Width: 40.19 in
• Rated Capacity Btu/hr: 24,000
• Capacity Range Btu/hr: 8,400-24,000
• EER2: 11.7
• Heating Capacity Range Btu/hr: 8,400-24,000
• HSPF2: 9.5
• Heating Electric Backup Heat Kits Capacity Ratio 5°F/47°F: 5/7.5/10 kW
• COP @ 5°F: 1.8
• Operating Cooling Range: 5~125°F (-15~52°C)
• Operating Heating Range: -22~75°F (-30~24°C)
• Input Voltage: 208-230/60/1
• MCA: 21
• MOP: 30
• Breaker Size A (Outdoor/Indoor): 35/15
• Outdoor Noise Level dB: 54
• Defrost Modes: 2 modes, normal and heavy
• Required Installation Clearance: 4" rear/14" front
• Basepan Heater: Yes
• Fan Motor: Variable Speed
• Airflow CFM: 795
• Metering Device: TXV
• Maximum Static Pressure W.C.: 0.8
• Control Voltage: 24V
• Thermostat Connections: R, Y, Y2, W, O, G
• Refrigerant Lineset Size (Suction, Discharge) In.: 3/4, 3/8
• Lineset Charge Ft/m: 15/4
• Maximum Line Length Ft/m: 150/45
• Maximum Height Ft/m: 50/15
