GE AVVS24DCXWA Zoneline Heat Pump, Single Package Vertical Air Conditioner, 230-208 Volt

Product Description

The GE AVVS24DCXWA Zoneline Heat Pump is a single package vertical air conditioner designed and assembled in America. This 230-208 volt unit features R454B refrigerant and inverter technology for variable speed operation, providing shorter recovery time, improved efficiency, sound quality, and dehumidification. It also features reverse cycle defrost for operation down to 0°F.

• Designed & Assembled in America
• Features R454B Refrigerant
• Inverter Technology for variable speed operation

Product Highlights

This GE Zoneline heat pump offers efficient cooling and heating with advanced features like reverse cycle defrost and SmartHQ WiFi capability for remote monitoring.

Product Information

Standard Information

• Brand: GENERAL ELECTRIC
• Manufacturer Part Number: AVVS24DCXWA
• Country of Origin: America

Technical Specifications

• Cooling BTU (230 / 208V): 22400
• COP2 @ 47F: 2.8
• EER: 8.9
• Heat Pump COP2@17F (Nominal/Max): 2 (230V Performance Data Listed)
• Heating BTU @17F (Nominal/Max): 17000
• Heating BTU Range @ 47F: 5,000-23,000
• HSPF2 Rating: 7.7
• Refrigerant Type: R454B
• SEER2: 16
• Sensible Heat Ratio: 0.7
• Cooling - Amperes: 10.9
• Cooling - Watts: 2430
• Cooling BTUH Range (@95F Outdoor): 5000 - 24,000
• Cooling BTUH (MAX - 115F): 20200
• Cooling BTUH (MAX - 75F): 27800
• Heat Pump - Amps: 4.4
• Heat Pump - Watts: 925
• Rated Heat Pump BTU: 21500
• Voltage (MAX): 230 V
• Voltage (MIN): 208 V
• Compressor: Inverter
• Energy Star: No
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: Power Supply Dependent
• EER2 (@230V): 8.8
• SEER2 (@230V): 16.0
• Cooling Amps (@230V): 10.9
• Cooling Watts (@230V): 2430
• Heat Pump BTUs (@230V): 21500
• COP (@230V): 2.8
• HSPF2 (@230V): 7.7
• Heat Pump Heating Amps (@230V): 4.4
• Heat Pump Heating Watts (@230V): 925
• Vent Location: Ducted into room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: 3
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Built-In WiFi
• Fresh Air Intake: No
• Overall Depth (in.): 24.125
• Overall Width (in.): 23.625
• Overall Height (in.): 31.875
• Voltage: 208-230V
• Circuit Breaker Size (Amps): Power Supply Dependent (20/30)
• Electric Heat Performance: See Description (Power Supply Dependent)
• Reverse Cycle BTU: 5000-23000
• AMPS: 15A, 20A, 30A
• COP: 3.5
• Dehumidification (Pints/Hr): 6.6
• Digital Controls: NO
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: HEAT/COOL
• Sea Coast Protection: YES
• Temprature Limiting: YES
• Certificate: ADA Compliant, AHRI Certified
• Maximum Voltage: 208V/230V
• Refrigerant: R-454B
• Wattage: 2430W
• Dehumidification (pts/hr): NA
• CFMs (@ 0.1 ESP): NA
