Product Description
The GE APPLIANCES PT7800SHSS Profile 30" Built-In Combination Convection Microwave/Convection Wall Oven is great for homeowners looking for both a microwave and oven combination. This appliance offers convection and microwave cooking for fast quality results. The lower oven features a 10-pass bake element and an 8-pass broil element.
- Convection microwave circulates heat for high-quality results.
- True European Convection achieves delicious results from a third heating element and fan combination.
- Self-clean with Steam Clean option.
Product Highlights
This combination microwave/wall oven features convection cooking, self-cleaning, and a delay-bake feature. It has a 1.7 cu. ft. microwave capacity and a 5.0 cu. ft. lower oven capacity.
Product Information
Standard Information
-
Brand: GE APPLIANCES
-
Manufacturer Part Number: PT7800SHSS
Technical Specifications
-
Handle Color: Stainless Steel
-
Installation: Above Warming Drawer
-
Handle: Designer Style
-
Oven Door Features: Big Clear View Oven Window (Lower)
-
Color Appearance: Stainless Steel
-
Total Capacity (cubic feet): 6.7 cu ft
-
Capacity (Cu. Ft.): 1.7 Upper / 5.0 Lower
-
Microwave Watts (IEC-705): 1000 W
-
Fuel Type: Electric
-
Oven Interior: 1 Halogen Interior Oven Light (Upper), 2 Halogen Interior Oven Lights (Lower), Hidden Bake
-
Oven Features: 10-Pass Bake Element, 8-Pass Broil Element
-
Configuration: Double Oven
-
Vent: Not Vented
-
Turntable Size: 16 in
-
Product Type: Double Oven, Microwave Oven Combination
-
Oven Rack Features: 1 Heavy-Duty Roller Rack, 2 Heavy-Duty Oven Racks, Ladder-Rack Positions (Lower)
-
Cooking Technology: Microwave/Convection
-
Self-Clean Oven Door Lock: Automatic (Lower)
-
Interior Oven Light: Halogen
-
Control Type: Dial, Glass Touch
-
Style: Built-In
-
Cooking System: True European Convection (Lower)
-
Sabbath Mode: Yes
-
Oven Cooking Modes: Convection Bake (Lower Oven), Convection Bake Multi-Rack (Lower Oven), Convection Roast (Lower Oven), Thermal Bake (Lower), Thermal Broil (Lower)
-
OU Certified: No
-
Microwave Sensor Cooking Controls: Convection, Cook, Defrost, Express, Reheat
-
Oven Cleaning Type: Self-Clean with Steam Clean Option
-
Cleaning Time: Variable with Delay Clean Option (Lower)
-
Oven Rack Positions (Single or Upper/Lower): 6
-
Oven Control Features: Audible Preheat Signal, Auto Recipe Conversion, Control Lock Capability, C° or F° Programmable, Defrost Mode, Delay Clean Option, Delay Start, Electronic Clock & Kitchen Timer, Hi / Low Broil, Proof Mode, Sabbath Mode, Temperature Probe, Warm Mode
-
Power Levels: 10
-
App Filter - Product Type: Wall Oven Microwave Oven Combination
-
App Filter - Control Type: Electronic touchpad
-
App Filter - Cooking Technology: Convection, Microwave Only
-
App Filter - Cabinet Width: Cooking 30 in. (Standard)
-
App Filter - Brillion Enabled: No
-
App Filter - Fuel Type: Electric
-
App Filter - Cleaning Type: Steam and Self-Clean
-
Bake Wattage: 2850W
-
Electrical Requirements: 208/240V ; 60Hz ; 30A
-
Amp Rating at 208V: 30
-
Hertz: 60
-
Broiler Wattage: 3400W
-
Convection Wattage: 2400W
-
KW Rating at 240V: 7.2
-
Amp Rating at 240V: 30
-
KW Rating at 208V: 5.4
-
Overall Depth: 26.75 in
-
Cabinet Width: 30 in
-
Oven Interior Dimensions (lower): 25 x 17-3/8 x 20-1/4
-
Overall Width: 29.75 in
-
Oven Interior Dimensions (upper): 20-1/16 x 8-1/2 x 17
-
Cutout Height (in): 42.25
-
Net Weight: 205 lb
-
Cutout Depth (in): 23.5
-
Depth with Door Open: 49.75 in
-
Overall Height: 43.375 in
-
Cutout Width (in): 28.625
-
Cutout Dimensions (w x h x d) (in.): 28-5/8 x 42-1/4 x 23-1/2
-
Dimensions: H: 43.375 in
-
W: 29.75
-
D: 26.75
