GE 9T51B0013 QB Dry Encapsulated General Purpose Transformer 3 KVA (240/480 VAC Primary, 120/240 VAC Secondary)

Product Description

GE 9T51B0013 is a QB Dry Encapsulated General Purpose Transformer designed for versatile and reliable power supply. It provides a primary voltage of two hundred forty/ four hundred eighty volts and a secondary voltage of one hundred twenty/ two hundred forty volts, making it suitable for various applications. With a three kVA power rating and a frequency of sixty hertz, this transformer is ideal for light and power loads.

• Core and coils are contained within a NEMA 3R non-ventilated weatherproof enclosure.
• Type QB and QMS units feature encapsulated core and coils.
• Wiring compartment includes ground stud.

Product Highlights

This transformer is built for both indoor and outdoor use, meeting rigorous performance standards.

Product Information

Standard Information

• Brand: GE
• Manufacturer: ABB Electrification

Technical Specifications

• Type: QB Dry Encapsulated
• Series: 9T51B
• Power Rating: 3 kVA
• Primary Voltage: 240/480 VAC
• Secondary Voltage: 120/240 VAC
• Frequency Rating: 60 Hz
• Mounting Type: Wall
• Enclosure Type: NEMA 3R
• Temperature Rating: 40 deg C
• Dimensions: 11.12 in H x 9.38 in W x 6.7 in D
• Insulation: IS-12
• Circuit Type: 14350 Frame
• Housing Material: Steel
