Product Description
Explore the features of the GC Valves S211GF24N5FG9, a robust 1-inch normally closed solenoid valve designed for controlling air, water, and gas flow in various industrial applications. Manufactured by GC Valves, this product ensures reliability and durability in demanding environments.
- Ideal for both indoor and outdoor applications with a NEMA 4/4X rating.
- Buna seals provide excellent resistance against petroleum products for versatile use.
- Operates efficiently within a wide temperature range up to 180 degrees Fahrenheit.
Product Highlights
This solenoid valve features a brass body that guarantees long-lasting performance and resistance to corrosion. The valve's diaphragm design offers precise flow control and low power consumption with only 10 watts of operation.
Product Information
Standard Information
-
Brand: GC Valves
-
MPN: S211GF24N5FG9
Technical Specifications
-
Media Compatibility: Air, Gas, Water, Light Oil
-
Wattage: 10 watts
-
Voltage: 24/50-60 volts
-
Pipe Size: 1 inch
-
Body Material: Brass
-
Seal Material: Buna (Nitrile/NBR)
-
Maximum Fluid Temperature: 180 degrees Fahrenheit
-
Operating Pressure Differential: 5 psi minimum, 200 psi maximum
