GC VALVES S211GF02V5FG9 Solenoid Valve 120V NPT Normally Closed Brass Body

Product Description

The GC Valves S211GF02V5FG9 is a robust solenoid valve designed for reliable operation in demanding industrial environments. Precisely engineered with a brass body and Viton seal, it ensures effective fluid control with a normally closed configuration. Ideal for applications involving air, gas, water, and light oil.

• Designed for 1 NPT pipe sizes, ideal for a variety of installations
• Capable of handling pressures up to 150 psi for water and light oil, and 200 psi for air and inert gases
• Equipped with a class F coil, operating optimally at 120/60 voltage

Product Highlights

Featuring a robust construction, the valve is crafted to offer a long service life with minimal maintenance requirements. Its coil insulation maintains integrity even at high temperatures, making it a reliable choice for HVAC systems and fluid handling applications.

Product Information

Standard Information

• Primary Material: Brass Body
• Seal Type: Viton/FKM

Technical Specifications

• Pipe Size: 1 inch
• Voltage: 120/60, 110/50
• Pressure Differential Range: Up to 150 psi for water and light oil, 200 psi for air
• Max. Fluid Temperature: 230 Degrees Fahrenheit
• Orifice Diameter: 1 inch
• Valve Design: 2-Way Piloted Diaphragm
