Gates 96416054 Quad-power 4 Cogged Ax Belt 56 in

Product Description

The GATES 96416054 is a Quad-Power 4 cogged V-belt in the AX profile, designed for demanding power transmission applications in HVAC, industrial, and mechanical drive systems. The cogged construction reduces heat buildup and increases flexibility, making it well-suited for smaller sheave diameters and variable-speed drives. With an outside length of 56 inches and a single-band configuration, this belt delivers consistent torque transfer in equipment that requires reliable belt-drive performance. It is installed by HVAC technicians, mechanical service technicians, and industrial maintenance professionals.

The 96416054 is used in belt-drive systems where an AX-profile cogged belt is specified. Typical applications include air handlers, blower assemblies, fan drives, compressors, and light industrial machinery. The cogged profile allows it to run cooler and with less energy loss than a standard wrapped belt of the same cross-section, which is an advantage in continuous-duty installations. Consult the equipment manufacturer's belt specification before installation to confirm the AX54 designation matches the drive requirement.

Key Features

• Cogged AX-profile construction reduces flex fatigue and heat on small-diameter sheaves
• 56-inch outside length for direct replacement in AX54-specified drives
• Single-band design for standard single-groove sheave configurations
• Quad-Power 4 series engineering for high power-to-size ratio in belt-drive applications
• Manufactured in the United States

Compatibility

Designed as an OEM-style replacement for belt-drive systems specifying an AX54 cogged V-belt. Verify sheave groove profile and center distance before installation.

Installation Notes

Installation should be performed by a qualified technician. De-energize and lock out the equipment before removing or installing any drive belt. Never pry a belt over a sheave with a tool; adjust center distance to allow proper seating. After installation, verify belt tension and alignment per the equipment manufacturer's specification before returning the unit to service.
