Gates 96416046 Quad-power 4 Cogged V-belt Ax 48 in

Product Description

The GATES 96416046 is a single-band, cogged V-belt from the 9641 Series Quad-Power 4 line, designed for high-performance power transmission in demanding drive applications. The AX section profile and cogged construction reduce bending resistance and heat buildup, allowing the belt to run cooler and transfer power more efficiently than a standard wrapped belt of the same cross-section. With a 48-inch outside length, this belt fits a wide range of industrial and HVAC drive setups. Licensed HVAC technicians and industrial maintenance professionals are the primary installers of this belt type.

The GATES 96416046 is suited for use in belt-driven equipment where the AX cross-section is specified, including HVAC air handlers, blower assemblies, compressors, and general industrial machinery. The cogged design is particularly effective in variable-speed and high-torque applications where belt slip and heat generation must be minimized. Manufactured in the United States, this belt meets the dimensional standards expected for AX-profile drives in both commercial and residential mechanical systems.

Key Features

• AX section cogged profile reduces bending resistance and heat for improved drive efficiency
• 48-inch outside length fits AX46-equivalent drive configurations
• Single-band construction for standard single-groove sheave installations
• Quad-Power 4 construction engineered for higher load capacity compared to conventional V-belts
• Manufactured in the United States

Compatibility

Designed as an OEM-style replacement for AX-section V-belt drives requiring a 48-inch outside length in HVAC, blower, and general industrial power transmission applications.

Installation Notes

Belt replacement should be performed by a qualified technician with the drive system fully de-energized and locked out per LOTO procedures. Never force the belt over sheave flanges using a pry bar, as this can damage the cord structure. Adjust sheave center distance to allow belt installation by hand, then tension to the drive manufacturer's specification using a belt tension gauge. Inspect sheaves for wear or misalignment before installing a new belt.
