Gates 96416044 Quad-power 4 Cogged V-belt AX44

Product Description

The GATES 96416044 is a Quad-Power 4 cogged V-belt from the Gates 9641 Series, designed for demanding drive applications where heat dissipation and flexibility are critical. This single-band AX-type belt features a cogged construction that reduces bending stress, allows operation on smaller-diameter sheaves, and improves overall efficiency compared to standard wrapped belts. With an outside length of 46 inches, it is suited for light industrial, HVAC, and equipment drive systems where precise belt fit and consistent power transmission are required. Installation is performed by qualified technicians servicing rotating drive equipment.

The 96416044 is used in single-belt drive configurations on equipment requiring an AX-profile cogged belt. Typical applications include fan drives, blower assemblies, compressors, and general-purpose machinery drives found in commercial and light industrial settings. The cogged profile allows the belt to run cooler and with less slippage than conventional wrapped belts, making it a reliable choice for moderate-load, continuous-duty drive systems.

Key Features

• Cogged construction reduces bending resistance and heat buildup during operation
• AX belt type provides compatibility with standard AX-profile variable-pitch and fixed sheaves
• Single-band design for straightforward single-groove drive configurations
• 46-inch outside length for precise fitment in matched drive systems
• Manufactured in the United States to Gates 9641 Series standards

Compatibility

Designed as an OEM-style replacement for drive systems requiring an AX-profile cogged V-belt with a 46-inch outside length in single-band configurations.

Installation Notes

Belt replacement should be performed by a qualified technician with the drive system fully de-energized, locked out, and tagged out per applicable OSHA lockout/tagout procedures. Proper sheave alignment and correct belt tension are essential for full service life — use a belt tension gauge where possible. Do not pry the belt over sheave flanges; always release tension through the drive adjustment mechanism before removal and installation.
