Gates 96416040 Quad-power 4 Cogged V-belt Ax 42 in

Product Description

The GATES 96416040 is a Quad-Power 4 cogged V-belt in the AX belt section, designed for demanding power transmission applications in HVAC, industrial, and mechanical drive systems. Built in the United States as part of the Gates 9641 Series, this single-band belt features a cogged construction that increases flexibility, reduces heat buildup, and improves efficiency over standard wrapped belts. With a 42-inch outside length, it fits a wide range of drive configurations encountered by HVAC technicians and mechanical service professionals during blower and fan drive replacements.

This belt is suited for residential and commercial HVAC blower drives, agricultural equipment, and light industrial machinery where an AX-section cogged belt is specified. The cogged profile allows it to run on smaller sheave diameters without excessive bending stress, making it a practical choice in space-constrained drive setups. HVAC technicians frequently install this belt type when servicing belt-drive air handlers, rooftop units, and fan coil blower assemblies that call for an AX40 replacement belt.

Key Features

• Cogged construction reduces flex fatigue and operating temperature compared to standard wrapped belts
• AX belt section with 42-inch outside length for a broad range of drive applications
• Single-band design for straightforward single-groove sheave installations
• Gates 9641 Series Quad-Power 4 construction for improved power capacity and service life
• Made in the United States

Compatibility

Designed as an OEM-style replacement for drives requiring an AX40 cogged V-belt. Fits single-groove sheaves sized for the AX belt section.

Installation Notes

Belt installation is typically performed by HVAC technicians or mechanical service professionals. Always de-energize the unit and lock out the disconnect before removing or installing drive belts. Never pry a belt over sheave flanges; adjust the drive center distance to allow proper belt seating, then re-tension according to the equipment manufacturer's deflection or tension specifications. Inspect sheaves for wear or misalignment before installing a new belt.
