Gastite XR3CPL-16 1 Coupling

Product Description

The Gastite XR3CPL-16 is a one-inch coupling designed for use with FlashShield metallically shielded corrugated stainless steel tubing. This system complies with ANSI LC 1 standards for Fuel Gas Piping Systems Using CSST and is listed with CSA, ICC, and IAPMO. The coupling features a unique design that ensures electrical continuity with minimal torque required for installation.

• Metal-to-metal seal enhances reliability
• Tool-less flare fitting design simplifies installation
• Reusable brass components provide a durable solution

Product Highlights

This coupling allows for easy splicing and addition to flexible gas tubing, making it ideal for various applications in heating and plumbing.

Product Information

Standard Information

• Product Name: 1 Coupling
• Brand: Gastite

Technical Specifications

• Max Approved Operating Pressure: 25 psi
• Operating Temperature Range: -40°F to 160°F
• Fitting Material: CA360 brass
• Listings: CSA Certificate 2728525, ICC-ES Report No. PMG 1066
• Feature: Jacket-Lock feature for tube protection
• Feature: Self-guiding fitting assembly simplifies use
• Feature: Fully reusable fitting design
• Feature: Multi-point seal for enhanced security
