Gastite XR3-APSTUB-11 3/4 x 1-1/2 Stub Out x 1/2 Female NPT

Product Description

The Gastite XR3-APSTUB-11 is a stub out fitting designed for efficient gas connections. This fitting is part of the FlashShield system, a metallically shielded corrugated stainless steel tubing system. It complies with ANSI LC 1 Fuel Gas Piping Systems and is certified by CSA, ICC, and IAPMO.

• Reduces joints needed, improving the installation process.
• Provides a fixed-point termination for gas appliances.
• Tool-less flare fitting simplifies assembly.

Product Highlights

The Gastite XR3-APSTUB-11 fitting is suitable for concealed use and features multi-point seals for durable performance. It enhances the appearance of gas installations.

Product Information

Standard Information

• Brand: Gastite
• MPN: XR3-APSTUB-11

Technical Specifications

• Max Approved Operating Pressure: 25 psi
• Operating Temperature Range: -40°F to 160°F
• Fitting Material: CA360 brass
• Stub-Out Material: Schedule 40 steel pipe
• Jacket-Lock Feature: Yes
• Metal Locking Feature: Yes
• Fully Reusable Fitting: Yes
• Angle Stub-Out: 72-½ degree
