Gast 1VAF-10-M100X Piston Pump 0.166 hp (1) 33K640

Brand: GAST
SKU: 1VAF-10-M100X
Availability: In Stock

Ships same day if ordered by 12 pm
$1,022.06
$1,022.06
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

GAST 1VAF-10-M100X is a piston air compressor and vacuum pump rated 0.166 hp that operates on 115 V single-phase corded electric power. The oil-less reciprocating design provides about 1.8 CFM free air flow, maximum vacuum of 27.5 in Hg and a maximum speed of 1,725 RPM. The unit features 1/4 in NPT ports, stainless steel valves, continuous (100%) duty rating, and thermal protection for industrial and OEM applications.

  • 0.166 hp, 115 V single-phase motor; continuous (100%) duty and thermal protection
  • Free air flow 1.8 CFM, maximum vacuum 27.5 in Hg, maximum speed 1,725 RPM
  • Oil-less reciprocating piston with stainless steel valves and 1/4 in NPT inlet/outlet

Product Highlights

Compact, tankless piston pump for vacuum or compressed air service with continuous-duty oil-less operation and 1/4 in NPT ports.

Product Information

Standard Information

  • Brand: GAST
  • Manufacturer Part Number: 1VAF-10-M100X
  • Country of Origin: United States
Technical Specifications
Manufacturer Part Number
1VAF-10-M100X
Brand
GAST
Product Type
Piston air compressor / vacuum pump
Operation
Oil-less
Piston Ring
Teflon-filled
Output Power
0.166 hp
Input Voltage
115 V AC
Input Current
3.5 A (60 Hz)
Phase
Single
Power Source
Corded electric
Duty Cycle
Continuous (100%)
Free Air Flow Rate
1.8 cfm
Maximum Vacuum
27.5 in Hg
Maximum Speed
1,725 RPM
Inlet Size
1/4 in NPT
Outlet Size
1/4 in NPT
Inlet Type
NPT
Outlet Type
NPT
Piston Type
Reciprocating
Pump Type
Piston
Valve Material
Stainless steel
Valve Type
Reed
Motor Type
Split-phase induction
Thermal Protection
Yes
Enclosure Rating
IP20
Sound Level
70 dBA
Dimensions
11.53 x 5.62 x 8.61 in (L x W x H)
Weight
21 lb
Number of Cylinders
1
Mounting Style
Thru-bolt
Stroke Length
3/4 in
Operating Temperature Range
41 to 104 Degrees F
Life Expectancy
16,000 hours
Series
Gast
Country of Origin
United States
Cross Reference / Replacement MPN
33K640
