Garlock 5030DU Self-Lubricating Metric DU Cylindrical Bushing

Product Description

The Garlock 5030DU is a self-lubricating cylindrical bushing designed for various applications requiring reliable performance. This component features a metric inner diameter of fifty millimeters and an outer diameter of fifty-five millimeters, making it suitable for a variety of mechanical systems.

• Metric dimensions for versatile application
• PTFE material enhances durability and performance
• Self-lubrication reduces maintenance needs

Product Highlights

The design of the Garlock 5030DU allows for effective load distribution and minimizes wear. This bushing operates under high pressure conditions, making it ideal for machinery requiring robust parts.

Product Information

Standard Information

• Brand: Garlock Bearings LLC
• Part Number: 102076345

Technical Specifications

• Inner Diameter: 50 mm
• Outer Diameter: 55 mm
• Length: 30 mm
• Material: PTFE
• Max. Static Pressure: 36,000 psi
• Max. Dynamic Pressure: 20,000 psi
• Temperature Range Minimum: -328 °F
• Temperature Range Maximum: 536 °F
