Product Description
The GARDNER BENDER GSW-13 heavy-duty SPDT toggle switch is suitable for industrial equipment or emergency lighting. This switch features ON-OFF-ON circuitry and screw terminals for quick connections. It is rated for 20 amps at 125V AC and 10 amps at 277V AC. The toggle switch has a 75°C maximum temperature rating.
- Features SPDT ON-OFF-ON circuitry.
- Rated for 20A at 125V AC and 10A at 277V AC.
- Ideal for industrial equipment and emergency lighting.
Product Highlights
Heavy-duty toggle switch with screw terminals, suitable for various applications requiring reliable ON-OFF-ON control.
Product Information
Standard Information
-
Brand: GARDNER BENDER
-
Manufacturer Part Number: GSW-13
-
Country of Origin: Taiwan, Province of China
Technical Specifications
-
Brand: Gardner Bender
-
Manufacturer: GB Electrical
-
MPN: GSW-13
-
UPCCode: 00032076890131
-
Voltage: 250 Volts
-
Material: Plastic
-
Terminal: Spdt
-
Contact Type: Spdt
-
Switch Style: Toggle Switch
-
Connector Type: Screw
-
Current Rating: 20 Amps
-
Operation Mode: ON-OFF-ON
-
Operating Voltage: 125 Volts
-
AC Adapter Current: 20 Amps
-
HP [Specifications]: 3/4 HP @ 125 to 250VAC
-
Amps [Specifications]: 20A @ 125V, 10A @ 277VAC
-
Terminals [Specifications]: Screw
-
Stem Length [Specifications]: 0.469"
-
Contact Form [Specifications]: SPDT
-
Switch Function [Specifications]: On/Off/On
-
Country of Origin (subject to change) [Specifications]: Taiwan, Province of China
-
Switch Type: SPDT
-
Mounting Type: Panel Mount
-
Part Number: GSW-13
-
Item model number: GSW-13
-
Size: 1 Count (Pack of 1)
-
Wattage: 2500 watts
-
Item Package Quantity: 1
-
Warranty Description: Warranty
-
Circuitry: ON-OFF-ON SPDT
-
3/4 HP at: 125/250V AC
-
Out of Package Height (in): 0.5
-
Out of Package Width (in): 1.13
-
Out of Package Length/Depth (in): 2
-
Pole and Throw Configuration: SPDT
-
Series: GSW
-
Product Type: Toggle Switch
-
Country of Origin: Taiwan (subject to change)
-
Contact Material: Brass
