Fujitsu UTY-RVRU Kagami touch screen wired controller

Product Description

The Fujitsu UTY-RVRU Kagami Controller is a touch-enabled controller compatible with 2-Wire H, J, and V-Series indoor units. It allows simultaneous control for up to 16 indoor units. Set up the Kagami controller via Bluetooth from your smartphone or directly on the controller. The controller features a sleek, minimalist design with an anti-fingerprint touch screen.

• Compatible with ACUH, ADUH, AMUG, ARUH, ASUH, AUUH Series
• Initial configuration and function setting via Bluetooth connection
• Large, easy to read, anti-fingerprint touch screen with auto dimming

Product Highlights

The Fujitsu UTY-RVRU Kagami Controller offers intuitive control and monitoring of general functions, including On/Off, Operation Mode, Fan Speed, and Air Flow Direction.

Product Information

Standard Information

• Brand: FUJITSU
• Manufacturer Part Number: UTY-RVRU
• Country of Origin: CHINA

Technical Specifications

• Controller Type: 2 Wire Thermostat
• Touch Screen: Yes
• Compatible with: ACUH, ADUH, AMUG, ARUH, ASUH, AUUH Series
• Set up Method: Set up your new Kagami controller via Bluetooth from your smartphone (or directly at the controller).
• Maximum number of indoor units: 16
• Power supply, consumption: 12Vdc, 83mA
• Power source: Indoor unit through 2-wire RC interface
• Display: 4 inch TFT LCD (480 × 480 pixels)
• Operating temperature range: 32-104 °F (0-40 °C)
• Storage temperature range: 14-140 °F (-10-60 °C)
• Operating / storage humidity range: 20-90%RH (no condensation)
• RoHS conformity: Compliant with RoHS directive: (2011/65/EU)
• Device connection to IDU: 2-cond cable, #16-22AWG, stranded, unshielded
