Fujitsu ASUA12TLAV2 Airstage 1 Ton VRF Heat Pump Compact Wall Mount Indoor Unit

Product Description

The Fujitsu ASUA12TLAV2 Airstage VRF Inner Unit is a heat pump with a 1 ton cooling capacity, utilizing variable refrigerant flow (VRF) technology. Airstage VR-II systems offer simultaneous cooling and heating operation. This compact wall mount system provides efficient heating and cooling in a streamlined design. It delivers exceptional heating and cooling performance while maintaining a sleek, space-saving design for versatile installation.

• 1 ton cooling capacity - 13,500 BTU's heating capacity
• Built in deodorizing and ionizing filters for better air quality
• Automatic swing louvers adjust airflow direction automatically

Product Highlights

The Fujitsu ASUA12TLAV2 provides efficient climate control with its compact design, energy-saving operation, and enhanced air quality features, suitable for residential and light commercial applications.

Product Information

Standard Information

• Brand: FUJITSU
• Manufacturer Part Number: ASUA12TLAV2
• Country of Origin: CN

Technical Specifications

• Nominal cooling: 12000
• Nominal Heating: 13500
• Electrical Designation: 1-60-208/230
• Refrigerant: R410A
• Suction Line Size: 1/2
• Liquid Line Size: 1/4
• Configuration: Wall Mounted
• Mounting Type: Wall
• Nominal Capacity: 12000 BTU
• Series: ASUA
• Sub-Brand: Airstage
• Type: Inner
• Indoor/Outdoor: Indoor
• Voltage Rating: 208-240 VAC
• Heating Capacity: 13.5 Kbtu/hr
• Cooling Capacity: 12 Kbtu/hr
• Flow Rate: 277, 330, 406 cfm
• Power Source: 208 to 230 V, 1 ph, 60 Hz
• Sound Level: 30, 35, 40 dBA
• Fan speed: Quiet
• Low noise: 24 dB(A)
