Frigidaire FHWC103TC1 10,000 BTU Window Room Air Conditioner (23-36 in Window Width) Replacement FHWC103TC1

Product Description

Frigidaire FHWC103TC1 is a 10,000 BTU window air conditioner designed to cool rooms up to 450 sq. ft. The unit operates at 115 V and about 890 watts, uses R-32 refrigerant, and fits windows 23 to 36 inches wide with a minimum height of 15.5 inches. It provides multi-directional airflow, three fan speeds, a washable dust prefilter with Clean Filter alert, a 24-hour programmable timer, dry/eco/sleep modes, remote control, and a window installation kit.

• 10,000 BTU cooling capacity; cools up to 450 sq. ft.; combined energy efficiency ratio 10.9
• Multi-directional 6-way airflow with three fan speeds and airflow ~423 / 465 / 545 CFM (low/med/high)
• Electronic controls with 24-hour programmable timer, remote control, washable dust prefilter, Clean Filter alert, and auto-restart

Product Highlights

Window-mounted 10,000 BTU unit for medium rooms; 115 V, ~890 W, 9.4 A; uses R-32 refrigerant; includes remote and window kit.

Product Information

Standard Information

• Brand: FRIGIDAIRE
• Manufacturer Part Number: FHWC103TC1

Technical Specifications

• Brand: Frigidaire
• Model Number: FHWC103TC1
• MPN: FHWC103TC1
• Cooling Capacity: 10,000 BTU
• Cooling Area: Up to 450 sq. ft.
• Input Voltage: 115 V
• Power Consumption: Approximately 890 Watts
• Current: 9.4 Amps (cool)
• Combined Energy Efficiency Ratio: 10.9
• SEER: 10.9
• Airflow (CFM) - Low/Med/High: 423 CFM / 465 CFM / 545 CFM
• Noise Level (dBA) - Low/Med/High: 53 dBA / 55 dBA / 59.5 dBA
• Fan Speeds: 3
• Modes: Cooling, Dehumidification, Dry / Eco / Sleep modes
• Timer: 24-hour programmable on/off timer
• Control Type: Electronic
• Remote Control: Yes
• Filter Type: Washable dust prefilter
• Filter Access Location: Front
• Filter Check Indicator: Yes (Clean Filter alert)
• Dehumidification (pints/hour): 3
• Auto Restart: Yes
• Air Discharge: Front of unit
• Air Direction Control: Manual (front air discharge)
• Installation Type: Window
• Window Opening Min Width: 23 inches
• Window Opening Max Width: 36 inches
• Window Opening Min Height: 15 1/2 inches
• Dimensions (H x W x D): 14 1/2 inches x 19 inches x 21 1/2 inches
• Weight: 57.76 lbs
• Power Cord Length: 72 inches
• Plug Type: LCDI 5-15P
• Refrigerant Type: R-32
• Package Includes: Window kit, washable filter, remote control
• Dehumidification: Yes
• Fresh Air: Yes
• Auto Fan: Yes
• Energy Saver: Yes
• Sleep Mode: Yes
• Prop 65 Label: Yes
• CSA Listed: Yes
• Energy Efficiency Verification (Canada): Yes
• Product Weight: 57.76 lbs
• UPC: 012505285271
