Friedrich VHA24R25RCQ Vert-I-Pak 24000 BTU Class VTAC with Heat Pump - 2.5 kW Electric Heat - 265V - R32 Refrigerant

Product Description

The Friedrich VHA24R25RCQ Vert-I-Pak vertical packaged air system offers a simpler way to condition multiple rooms. This 265V unit features 22,600 BTUs of cooling and 19,500 BTUs of heat from the heat pump, along with a 2.5 kW electric heater. It uses R-32 refrigerant, which is more efficient and has a lower Global Warming Potential (GWP).

• Utilizes R-32 refrigerant for improved efficiency and lower GWP.
• Fits neatly into a typical mechanical closet for versatile indoor spaces.
• Features 10.6 EER2, 11.9 SEER2, and 6.7 HSPF2 ratings.

Product Highlights

The Friedrich Vert-I-Pak is ideal for extended stay properties, suites, assisted living facilities, and student housing, providing individual, in-room temperature control.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA24R25RCQ

Technical Specifications

• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs (@ 0.1 ESP): 580
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 2.5
• Cooling BTUs (@265V): 22600
• EER2 (@265V): 10.6
• SEER2 (@265V): 11.9
• Cooling Watts (@265V): 2132
• Heat Pump BTUs (@265V): 19500
• HSPF2 (@265V): 6.7
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 52
• Voltage: 265-277V
• Circuit Breaker Size (Amps): 15
• Cooling BTU: 24000
• Reverse Cycle BTU: 19500
• AMPS: 15A
• EER: 11.0
• COP: 3.3
• Digital Controls: NO
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• Item Type: Vertical Package Unit
• Cooling Capacity: 22600 BTU
• Heating Capacity: 19500 BTU
• Watts: 2450
