Product Description
The FRIEDRICH VHA24K34RCQ VTAC with heat pump offers the simplicity of single room ACs with the aesthetics of central HVAC systems. A customizable and reliable solution, this air conditioner is perfect for extended stay hotels, assisted living, and student housing, staying tucked away and out of sight.
- R-32 refrigerant
- Compact and lightweight
- Unique free-floating chassis
Product Highlights
Vert-I-Pak fits neatly into a typical mechanical closet, so you can create indoor living spaces that are more versatile.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: VHA24K34RCQ
-
Country of Origin: MEXICO
Technical Specifications
-
Brand: Friedrich
-
Type: Cooling With Heat Pump
-
Cooling BTU: 24000 Btu
-
Reverse Cycle BTU: 19500
-
Voltage: 208/230V
-
AMPS: 20A
-
EER: 11.0
-
COP: 3.3
-
Auto Restart: YES
-
Fan Modes: Constant/Cycle (Hi/Med/Auto)
-
Freeze Protection: YES
-
Front Desk Connection: YES
-
Modes: Heat/Cool/Heat-Pump
-
Sea Coast Protection: YES
-
Temprature Limiting: YES
-
Refrigerant Type: R32
-
Compressor: Standard
-
Energy Star: No
-
CFMs (@ 0.1 ESP): 580
-
Includes Heat Mode: Yes
-
Heat Type: Heat Pump with Back-Up Electric
-
Electric Heat kW: 3.4
-
Cooling BTUs (@230V): 22600
-
EER2 (@230V): 10.6
-
SEER2 (@230V): 12.1
-
Cooling Amps (@230V): TBD
-
Cooling Watts (@230V): 2132
-
Heat Pump BTUs (@230V): 19500
-
HSPF2 (@230V): 6.7
-
Heat Pump Heating Amps (@230V): TBD
-
Heat Pump Heating Watts (@230V): TBD
-
Vent Location: Ducted Into Room
-
Make-Up Air: No
-
Energy Saver Mode: No
-
Fan Speeds: High or Low
-
Control Type: Wall Thermostat Required (NOT INCLUDED)
-
Connectivity: Not WiFi Compatible
-
Fresh Air Intake: No
-
Overall Depth (in.): 23
-
Overall Width (in.): 23
-
Overall Height (in.): 52
-
Circuit Breaker Size (Amps): 20
-
Amperage: 15.4 amp
-
Average Coverage Area: 1400-1500 sq. ft.
-
BTU Heat Rating: 24000 Btu
-
Commercial/Residential: Commercial/Residential
-
Heating Method: Heat Pump
-
Package Quantity: 1
-
Cooling Capacity: 22600 BTU
-
Heating Capacity: 19500 BTU
-
Watts: 3350
