Friedrich VHA18R75RCQ Vert-I-Pak 18000 BTU with Heat Pump - 7.5 kW Electric Heat - 265V - R32 Refrigerant

Product Description

The FRIEDRICH VHA18R75RCQ Vert-I-Pak vertical packaged air system offers a simpler way to condition multiple rooms. This 265V unit features 17,800 BTUs of cooling and 16,200 BTUs of heat from the heat pump, along with a 7.5 kW electric heater. It uses R-32 refrigerant, which is more efficient and has a lower Global Warming Potential (GWP).

• R-32 refrigerant for improved efficiency and reduced environmental impact.
• Fits neatly into a typical mechanical closet for versatile indoor living spaces.
• Features 10.6 EER2, 12.1 SEER2, and 6.7 HSPF2 ratings.

Product Highlights

Ideal for extended stay properties, suites, assisted living facilities, and student housing, providing individual, in-room temperature control.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA18R75RCQ
• Country of Origin: MEXICO

Technical Specifications

• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• Dehumidification (pts/hr): NA
• Air Delivery CFM: 560
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 7.5
• Cooling BTU: 17800
• EER2 (@265V): 10.6
• SEER2 (@265V): 12.1
• Cooling Amps (@265V): TBD
• Cooling Watts (@265V): 1679
• Heat Pump BTUs (@265V): 8200
• COP (@265V): TBD
• HSPF2 (@265V): 6.7
• Heat Pump Heating Amps (@265V): TBD
• Heat Pump Heating Watts (@265V): TBD
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 47
• Voltage: 265-277V
• Circuit Breaker Size (Amps): 45
• Heating Amps: 29.1
• Minimum Circuit Ampacity: 36.4
• Branch Circuit Fuse (Amps): 45
• Basic Heater Size: 7.5 kW
• Reverse Cycle BTU: 16700
• EER: 11.0
• Digital Controls: NO
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• BtuH Cooling: 13100
• BtuH Heating: 25600
• Refrigerant: R-32
• Type: Single Package Heat Pump
