Friedrich VHA12K50RCQ Vert-I-Pak 12000 BTU Class VTAC with Heat Pump 5.0 kW Electric Heat

Product Description

The FRIEDRICH VHA12K50RCQ Vert-I-Pak is a customizable and reliable VTAC unit with heat pump, perfect for extended stay hotels, assisted living, and student housing. This air conditioner stays tucked away and out of sight. It features 12000 BTU cooling and 10600 BTU reverse cycle. Requires a 30 Amp circuit and operates on 208/230V.

• R-32 refrigerant for improved efficiency and lower Global Warming Potential (GWP).
• Fits neatly into a typical mechanical closet for versatile indoor living spaces.
• Features a free-floating chassis design and superior insulation for ultra-quiet operation.

Product Highlights

The Friedrich Vert-I-Pak offers a simpler way to condition multiple rooms with individual, in-room temperature control. Ideal for extended stay properties, suites, assisted living facilities and student housing.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA12K50RCQ
• Country of Origin: Mexico

Technical Specifications

• Brand: Friedrich
• Type: Packaged Terminal Air Conditioner with Heat Pump
• Cooling BTU: 12000
• Reverse Cycle BTU: 10600
• Voltage: 230 V
• AMPS: 30A
• EER: 11.0
• COP: 3.3
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs (@ 0.1 ESP): 420
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 5.0
• Cooling BTUs (@230V): 11200
• EER2 (@230V): 10.6
• SEER2 (@230V): 12.3
• Cooling Amps (@230V): TBD
• Cooling Watts (@230V): 1057
• Heat Pump BTUs (@230V): 10400
• HSPF2 (@230V): 6.3
• Heat Pump Heating Amps (@230V): TBD
• Heat Pump Heating Watts (@230V): TBD
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 32
• Circuit Breaker Size (Amps): 30
• Amps Heating: 22.5 A
• BTU Heating: 12000
• Number of Speeds: 2
• Watts Heating: 5000 W
• Phase: 1
• Refrigerant Charge: 28.7 oz
• Air Discharge: 60
• Manufacturers Part Number: VHA12K50RCQ
• CFM: 420 CFM
• Remote Control: No
• Controls: Electronic
• Hertz: 60 Hz
• Amp Circuit: 28.2 A
• Amps Cooling: 6.4 A
• Temperature Range Cooling: 60 to 115 °F
• Temperature Range Heating: 40 to 70 °F
• Energy Efficiency Rating (EER): 10.6
• Coverage Area: 450-550 ft²
• Air Conditioner Type: Vertical Packaged
• Cooling Area: 550
• SEER2 Rating: 12.3
• EER2 Rating: 10.6
• Operation Mode: Cooling; Heating
• Air Flow: 460
• Plug Face: Hard Wire
• Cooling Method: Air-Cooled Ducted; Air-Cooled Vented
• Commercial/Residential: Commercial
• Heat Pump: Yes
• UNSPSC Code: 40101701
