Friedrich VHA12K25RTQ Vertipak 2/2/1ph Upflow Vertical Heat Pump

Product Description

The FRIEDRICH VHA12K25RTQ Vertipak is a 1-package vertical heat pump with a voltage rating of 208/230 Volt AC. It features a unique free-floating chassis and is compatible with wired and wireless energy management systems. The unit is completely self-contained for ease of use. Designed for front, left, or right installation.

• Compatible with wired and wireless energy management systems
• Completely self-contained
• Vibration isolators mounted under the chassis mounting feet

Product Highlights

The Vertipak heat pump offers easy installation and features a corrosion-resistant interior. It includes a standard safety power disconnect and an electronic control panel for easy diagnostics.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA12K25RTQ
• Country of Origin: MEXICO

Technical Specifications

• Brand Name: Vert-I-Pak
• Category: HVAC/R & Fans
• Cooling Capacity: 11500 BTU/Hour
• Current Rating: 4.9 Amp
• Frequency Rating: 60 Hertz
• Installation: Front, Left, Right
• Manufacturer Name: Friedrich
• Number Of Phases: 1
• Power Rating: 1045 Watt
• Series/Model: VHA12K
• Type: 1-Package, Vertical
• Voltage Rating: 208/230 Volt AC
• Approval: ETL (Canada)
• UNSPSC Code: 40101806
• Catalog Number: VHA12K25RTQ
• Manufacturer Part Number: VHA12K25RTP
• Heating Capacity: 10600 BTU/Hour
• Heating Power Rating: 940 Watt
• Heater Size: 2.5/3.4/5 Kilowatt
• Heating Current Rating: 4.5 Amp
• Indoor Motor Rating: 1/4 HP
• Energy Efficiency Ratio: 11 EER
• Applicable Standard: ASHRAE, ULCDTP
• EER2: 10.6
• SEER2: 11.9
• Heat Pump BTUs: 10600
• COP: 3.1
• HSPF2: 6.3
• Electric Heat: 2.5 kW
• Air Delivery CFM: 350
• BtuH Cooling: 12,000
• BtuH Heating: 10,400
• EER: 10.6
• Fuse Size T.D.: 15
• Volts: 230/208
