Friedrich VHA09R50RCQ Vert-I-Pak 9000 BTU Class VTAC with Heat Pump 5.0 kW Electric Heat 265V R32 Refrigerant

Product Description

The Friedrich VHA09R50RCQ Vert-I-Pak vertical packaged air system offers a simpler way to condition multiple rooms. This 265V unit features 9400 BTUs of cooling and 8600 BTUs of heat from the heat pump, with a 5.0 kW electric heater. It uses R-32 refrigerant, which is more efficient and has a lower Global Warming Potential (GWP).

• R-32 refrigerant for improved efficiency and lower environmental impact.
• Fits neatly into a typical mechanical closet for a visually appealing living space.
• Pre-wired, charged, and piped for easy installation, requiring only electrical hook up.

Product Highlights

Ideal for extended stay properties, suites, assisted living facilities, and student housing, providing individual in-room temperature control.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA09R50RCQ
• Country of Origin: MEXICO

Technical Specifications

• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• Air Delivery CFM: 360
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 5.0
• Cooling BTUs (@265V): 9400
• EER2 (@265V): 10.6
• SEER2 (@265V): 12.3
• Cooling Amps (@265V): TBD
• Cooling Watts (@265V): 887
• Heat Pump BTUs (@265V): 8600
• HSPF2 (@265V): 6.3
• Heat Pump Heating Amps (@265V): TBD
• Heat Pump Heating Watts (@265V): TBD
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 32
• Voltage: 265-277V
• Circuit Breaker Size (Amps): 30
• Cooling BTU: 9,400
• Reverse Cycle BTU: 8300
• AMPS: 30A
• EER: 11.0
• Digital Controls: NO
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• Cooling Power (Watts): 855
• Sensible Heat Ratio: 0.77
• Heater Size: 5.0 kW
• Heating BTU: 17,000
• COP @ 47 degrees: 3.0
• Heating Power (Watts): 845
• Heating Current (Amps): 3.2
• Heater Watts: 5,000
• Heating Current Amps: 20.1
• Branch/Circuit/Fuse MOP/MCOP: 30
• Voltage (1 Phase, 60 Hz): 265
• Volt Range: 292-239
• Cooling Current (Amps): 3.8
• Amps L.R.: 21.0
• Amps F.L.: 3.5
• Indoor Motor (HP): 1/4
• Indoor Motor (A): 1.2
• Vent CFM: 60
• R410A Charge (oz.): 39.0
• BtuH Cooling: 7100
• BtuH Heating: 17000
• Depth: 23
• Height: 32
• Refrigerant: R-32
• Type: Single Package Heat Pump
• Volts: 265
• Width: 23
