Friedrich VHA09R25RCQ Vert-I-Pak 9000 BTU Class VTAC with Heat Pump 2.5 kW Electric Heat 265V R32 Refrigerant

Product Description

The Friedrich VHA09R25RCQ Vert-I-Pak vertical packaged air system offers a simpler way to condition multiple rooms. This 265V unit features 9400 BTUs of cooling and 8600 BTUs of heat from the heat pump, with a 2.5 kW electric heater. It utilizes R-32 refrigerant, which is more efficient and has a lower Global Warming Potential (GWP).

• Features R-32 refrigerant.
• Requires a wall thermostat (not included).
• Installs easily into a closet on an outside wall.

Product Highlights

Ideal for extended stay properties, suites, assisted living facilities, and student housing. Compact design eliminates clutter and provides individual in-room temperature control.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA09R25RCQ

Technical Specifications

• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs (@ 0.1 ESP): 360
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 2.5
• Cooling BTUs (@265V): 9400
• EER2 (@265V): 10.6
• SEER2 (@265V): 12.3
• Cooling Watts (@265V): 887
• Heat Pump BTUs (@265V): 8600
• HSPF2 (@265V): 6.3
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 32
• Voltage: 265-277V
• Circuit Breaker Size (Amps): 15
• Cooling BTU: 9000
• Reverse Cycle BTU: 8300
• AMPS: 15A
• EER: 11.0
• COP @ 47 degrees: 3.0
• Digital Controls: NO
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• BTU Cooling Rating: 9000 Btu/h
• BTU Heat Rating: 8600 Btuh/h
• Refrigerant: R-32
• Type: FVHA09R25RCQ
• Watts: 2.5
• Cooling Power (Watts): 855
• Sensible Heat Ratio: 0.77
• Heater Size: 2.5 kW
• Heating BTU: 8,500
• Heating Power (Watts): 845
• Heating Current (Amps): 3.2
• Heater Watts: 2,500
• Heating Current Amps: 10.6
• Minimum Circuit Ampacity: 13.1
• Branch/Circuit/Fuse MOP/MCOP: 15
• Voltage (1 Phase, 60 Hz): 265
• Volt Range: 292-239
• Cooling Current (Amps): 3.8
• Amps L.R.: 21.0
• Amps F.L.: 3.5
• Indoor Motor (HP): NA
• Indoor Motor (A): NA
• INDOOR CFM LOW/HIGH .10" ESP.10" ESP: 420/450
• INDOOR CFM LOW/HIGH .15" ESP.10" ESP: 405/425
• INDOOR CFM LOW/HIGH .20" ESP.10" ESP: 385/400
• INDOOR CFM LOW/HIGH .25" ESP.10" ESP: 355/375
• INDOOR CFM LOW/HIGH .30" ESP.10" ESP: 320/350
• Vent CFM: 60
