Friedrich VHA09K34RCQ Vert-I-Pak 9000 BTU Class VTAC with Heat Pump 3.4 kW Electric Heat

Product Description

The FRIEDRICH VHA09K34RCQ Vert-I-Pak is a customizable and reliable VTAC with heat pump, perfect for extended stay hotels, assisted living, and student housing. This air conditioner stays tucked away and out of sight, offering the aesthetics of central HVAC systems. The VHA09K34RCQ includes a 3.4 Kw electric heater and requires a 20 Amp circuit.

• Cooling With Heat Pump
• Customizable and reliable solution
• Perfect for extended stay hotels, assisted living, and student housing

Product Highlights

The FRIEDRICH Vert-I-Pak fits neatly into a typical mechanical closet, so you can create indoor living spaces that are more versatile.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: VHA09K34RCQ

Technical Specifications

• Brand: Friedrich
• Type: Cooling With Heat Pump
• Cooling BTU: 9000
• Reverse Cycle BTU: 8300
• Voltage: 208-230V
• AMPS: 20A
• EER: 11.0
• COP: 3.3
• Auto Restart: YES
• Fan Modes: Constant/Cycle (Hi/Med/Auto)
• Freeze Protection: YES
• Front Desk Connection: YES
• Modes: Heat/Cool/Heat-Pump
• Sea Coast Protection: YES
• Temprature Limiting: YES
• Refrigerant Type: R32
• Compressor: Standard
• Energy Star: No
• CFMs (@ 0.1 ESP): 360
• Includes Heat Mode: Yes
• Heat Type: Heat Pump with Back-Up Electric
• Electric Heat kW: 3.4
• Cooling BTUs (@230V): 9400
• EER2 (@230V): 10.6
• SEER2 (@230V): 12.3
• Cooling Amps (@230V): TBD
• Cooling Watts (@230V): 887
• Heat Pump BTUs (@230V): 8600
• HSPF2 (@230V): 6.3
• Heat Pump Heating Amps (@230V): TBD
• Heat Pump Heating Watts (@230V): TBD
• Vent Location: Ducted Into Room
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: High or Low
• Control Type: Wall Thermostat Required (NOT INCLUDED)
• Connectivity: Not WiFi Compatible
• Fresh Air Intake: No
• Overall Depth (in.): 23
• Overall Width (in.): 23
• Overall Height (in.): 32
• Circuit Breaker Size (Amps): 20
