Product Description
The Friedrich UCT14B30A Uni-Fit models offer a universal fit for easy installation in new or existing sleeves from 24 1/2" - 27". Engineered for quiet operation, it features built-in Wi-Fi control that you can manage from your smartphone. This unit has a cooling capacity of 14,000 BTU and operates at 230/208V.
- Through the Wall Unit
- 14000 BTU
- Air Conditioner Only
Product Highlights
The Friedrich UCT14B30A is designed for easy installation and quiet operation, with smart features for modern convenience.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: UCT14B30A
-
Country of Origin: China
Technical Specifications
-
BTU: 14000
-
Voltage: 230/208v
-
Type of Through-the-Wall:: 26" Through-the-Wall
-
Sleeve Required for Install:: Yes
-
Fits Sleeve Size (in.):: 26
-
Refrigerant Type:: R32
-
Compressor:: Standard
-
Energy Star:: No
-
Dehumidification (pts/hr):: 2.15
-
CFMs:: 265
-
Includes Heat Mode:: No
-
Cooling BTUs (@230V):: 14000
-
EER (@230V):: 9.4
-
CEER (@230V):: 9.3
-
Cooling Amps (@230 Volt):: 7.2
-
Cooling Watts (@230 Volt):: 1490
-
Vent Location:: Front Top
-
Make-Up Air:: No
-
Energy Saver Mode:: Yes
-
Fan Speeds:: 3
-
Control Type:: Electronic/Digital
-
Filter Access:: Front Lift Out
-
Connectivity:: Built-In WiFi
-
24 Hour ON/OFF Timer:: Yes
-
Remote Control:: Yes
-
Fresh Air Intake:: No
-
Sleep Mode:: No
-
Width (in.):: 24.25
-
Depth (in.):: 20.313
-
Height (in.):: 14.5
-
Max. Wall Thickness (in.):: 16.25
-
Wall Cut-Out Width (in.):: 26.125
-
Wall Cut-Out Height (in.):: 15.75
-
Extension Into Room (Min)(in.):: 3.75
-
Certifications:: AHAM, UL, CUL
-
Voltage:: 208-230V
-
Plug Face (NEMA):: 6-15P
-
Circuit Breaker Size (Amps):: 15
-
Cord Length:: 6'
-
EER: 9.4
-
Amps: 7.2 A
-
Watts: 1,490
-
Series: UNI-FIT
-
CEER Rating: 9.3
-
Duty Rating: Residential Grade
-
Cooling Capacity: 14,000 BtuH
-
Number of Speeds: 3
-
Refrigerant Type: R32
-
Smart Connectivity: WiFi Control
-
Operation Mode - HVAC: Cooling Only
-
Programming Capability: 24-hr. On/Off Timer
-
Fits Wall Sleeve - H x W x D: 15 1/2 in x 25 7/8 in x 16 3/4 in
-
Seacoast Corrosion Protection: Front and Rear Coil
-
NEMA Plug Configuration - HVAC: 6-20P
-
Cooling BTU: 14000 BTU
-
Room Size: Large
-
Cooling Speeds: 3
-
Number of Fan Speeds: 3 Fan Speeds
-
Heat/Cool: No
-
No. of Air Flow Directions: 8
-
Moisture Removal (Pints/hr): 4.44 Pints/hr
-
Filter Description: Washable air filter
-
Washable Filter: Yes
-
Charcoal Filter: No
-
Inverter Technology: No
-
Chassis Type: Thru the Wall
-
Additional Features: Built-in Wi-Fi control on the go with the FriedrichGo app, Smart home / voice command device compatability (Amazon Alexa or Google Home)
or Google Home)
-
Universal Fit Wall Sleeve: Yes
-
Smart: Yes
-
WiFi Connected: Yes
-
Wifi/App Controllable: Wifi/Smartphone App Controllable
-
Smart Features: App Controllable, Status Monitoring & Alert, Works with Voice Assistant
-
Works with: Amazon Alexa
-
Automatic Timer: Yes
-
Delay Timer: No
-
Automatic Shut Off/Sleep Mode: Yes
-
Quietest: No
-
Remote Control Included: Yes
-
Replacement Sleeve Included: No
-
Upgradeable Filter: No
-
Trim Kit Included: Yes
-
Energy Efficiency Ratio: 9.4 EER
-
Power Cord Length (in.): 72 Inches
-
Power Requirements: 220 Volt 15 Amp Dedicated Circuit (Tandem Plug)
-
Voltage (V): 230 Volts
-
Amperage: 15 Amps
-
Auto Restart: Yes
-
Power Cord Location: Left Side
-
Cooling Amps: 7.5 Amps
-
Outlet Type: 230V Grounded Outlet
-
ADA Compliant: No
-
CSA Listed: No
-
ETL Listed: No
-
UL Listed: Yes
-
Operation: Cooling
-
Refrigerant: R-32
-
Dimensions: H: 14.50 in
-
Dimensions: W: 24.25 in
-
Dimensions: D: 20.13 in
-
Product Height: 14.5 Inches
-
Product Width: 24.25 Inches
-
Product Depth: 20.31 Inches
