Friedrich PZE07K3SC 7000 BTU Class Select Series 12.0 EER PTAC Air Conditioner with Electric Heat - 20 Amp - 230 Volt - R32 Refrigerant

Product Description

The Friedrich PZE07K3SC is a quiet and efficient ZoneAire Select PTAC unit suitable for commercial and residential applications. This 7000 BTU air conditioner with electric heat has an EER of 12.0 and utilizes 208 / 230V electricity. It features a 2-speed fan plus auto fan for better circulation and uses R32 refrigerant, which is more efficient and has a lower Global Warming Potential (GWP) than R410A.

• Quiet and efficient operation suitable for both commercial and residential use.
• Utilizes R32 refrigerant, offering enhanced efficiency and a lower Global Warming Potential.
• Features aluminum end plates and DiamonBlue Advanced Corrosion protection for durability.

Product Highlights

The Friedrich PZE07K3SC PTAC unit provides reliable cooling and heating with user-friendly digital controls and robust construction.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: PZE07K3SC

Technical Specifications

• Type of Through-the-Wall: 42" PTAC
• Sleeve Required for Install: Yes
• Fits Sleeve Size (in.): 42
• Refrigerant Type: R32
• Compressor: Standard
• Energy Star Certified: No
• Dehumidification (pts/hr): 0.3
• CFMs: 365 / 424 (L / H)
• Includes Heat Mode: Yes
• Heat Type: Electric Resistance Only
• Cooling BTUs (@208V): 6800
• EER (@208V): 12.0
• Cooling Amps (@208V): 2.7
• Cooling Watts (@208V): 580
• Electric Heat Strip Size (kW @208V): 3.6
• Electric Heating BTUs (@208V): 12284
• Electric Heating Amps (@208V): 17.3
• Electric Heating Watts (@208V): 3600
• Cooling BTUs (@230V): 7200
• EER (@230V): 12.0
• Cooling Amps (@230V): 2.6
• Cooling Watts (@230V): 600
• Electric Heat Strip Size (kW - @230V): 3.6
• Electric Heating BTUs (@230V): 12284
• Electric Heating Amps (@230V): 15.7
• Electric Heating Watts (@230V): 3600
• Vent Location: Front Top
• Make-Up Air: No
• Energy Saver Mode: No
• Fan Speeds: 2
• Control Type: Electronic/Digital
• Filter Access: Top Lift Out
• Connectivity: Not WiFi Compatible
• 24 Hour ON/OFF Timer: No
• Remote Control: No
• Fresh Air Intake: Yes
• Sleep Mode: No
• Certifications: ETL, DDC, AHRI
• Voltage: 208-230V
• Plug Face (NEMA): 6-20P
• Circuit Breaker Size (Amps): 20
• Cord Length: 67"
• Cord Included: Yes
• Plug Type: NEMA 6-20
• Heat: Electric Heat
• Fits Standard 42" x 16" Sleeve: Yes
• Automatic Restart: Yes
• Seacoast Protection: Yes
• Freeze Protection: Yes
• Number of Fan Motors: 2
• Energy Efficiency Rating (EER): 12
• Sleeve Included: No
• Exterior Grille Included: No
• Maximum Cooling Watts: 585
• Maximum Cooling Amps: 2.7
• Actual Cooling BTUs @ 208V: 6800
• Actual Cooling BTUs @ 230V: 7000
• CFM (Cool/Wet Coil) - High: 350
• CFM (Cool/Wet Coil) - Low: 330
• Product Length: 42
• Product Width: 21.5
• Product Height: 16
