Product Description
The Friedrich PDE15K5SGR3 is a high-efficiency 15000 BTU PTAC air conditioner designed for cooling and heating small to medium-sized spaces. This PTAC unit features R32 refrigerant, which is up to 12% more efficient than R410A. It operates on 208-230V and includes a 30 Amp power cord for quick installation.
- Features R32 refrigerant, offering up to 12% more efficiency than R410A.
- Operates with two fan speeds and includes a constant fan mode for consistent white noise.
- Equipped with a digital control pad, LCD readout, and electronic one-touch operation.
Product Highlights
This Friedrich PTAC unit provides efficient cooling and heating with user-friendly features and is designed for easy maintenance.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: PDE15K5SGR3
Technical Specifications
-
Type of Through-the-Wall: 42" PTAC
-
Sleeve Required for Install: Yes
-
Fits Sleeve Size (in.): 42
-
Refrigerant Type: R32
-
Compressor: Standard
-
Energy Star: No
-
Dehumidification (pts/hr): 3.17
-
CFMs: 306 / 341 (L / H)
-
Includes Heat Mode: Yes
-
Heat Type: Electric Resistance Only
-
Cooling BTUs (@208V): 14400
-
EER (@208V): 10.6
-
Cooling Amps (@208V): 6.5
-
Cooling Watts (@208V): 1380
-
Electric Heat Strip Size (kW @208V): 5.0
-
Electric Heating BTUs (@208V): 17060
-
Electric Heating Amps (@208V): 24.0
-
Electric Heating Watts (@208V): 5000
-
Cooling BTUs (@230V): 14700
-
EER (@230V): 13
-
Cooling Amps (@230V): 2.7
-
Cooling Watts (@230V): 550
-
Electric Heat Strip Size (kW - @230V): 5.0
-
Electric Heating BTUs (@230V): 17060
-
Electric Heating Amps (@230V): 21.7
-
Electric Heating Watts (@230V): 5000
-
Vent Location: Front Top
-
Make-Up Air: No
-
Energy Saver Mode: No
-
Fan Speeds: 2
-
Control Type: Digital
-
Filter Access: Top Lift Out
-
Connectivity: Not WiFi Compatible
-
24 Hour ON/OFF Timer: No
-
Remote Control: Not Included
-
Fresh Air Intake: Yes
-
Sleep Mode: No
-
Net Weight (lbs.): 114.7
-
Certifications: ULCDTP, UL, AHRI
-
Voltage: 208-230V
-
Plug Face (NEMA): 6-30P
-
Circuit Breaker Size (Amps): 30
-
Cord Length: 67"
-
Width: 42 in
-
Depth: 21-1/2 in
-
Height: 16 in
-
Coverage Area: 900 ft²
-
Assembly Required: No
-
Phase: 1
-
Manufacturers Part Number: PDE15K5SGR3
-
Brand: Friedrich
-
Hertz: 60 Hz
-
Amp Circuit: 30 A
-
Decibels: 58
-
ADA Compliant: No
-
Maximum Cooling Watts: 1,420 Watts
-
Maximum Cooling Amps: 6 Amps
-
Smart: Remote Monitoring
-
WiFi: No
-
Cooling Capacity (BTU): 14,700 BTU
-
Model: PDE15K5SGR3
-
Compressor LRA: 35.2
-
Power Factor: 0.97
-
Current Amps: 6.0
-
Volt Range: 253-187
-
Compressor RLA: 5.0
-
Outdoor Fan Motor HP: 0.086
-
Vent CFM: 75
-
Indoor CFM Low: 306
-
Indoor CFM High: 341
-
Sensible Heat Ratio: 67%
-
Moisture Removal: 3.17
-
Heater Size: 5
-
Cooling Watts: 1420
-
Cooling BTU: 15,000
-
Refrigerant Charge: 36 oz
