Product Description
The Friedrich KCVL28B30A Kuhl Series Cooling Only Smart Window Air Conditioner features precision inverter technology. This commercial-grade air conditioner is constructed with high-quality materials and components. Integrated WiFi works with smartphones, Amazon Alexa, and Google Home. The KCVL28B30A uses R32 refrigerant and Quietmaster technology, making it quieter than competitor products. It can be installed in a window or wall and includes heavy-duty side curtains for window installation.
- R32 Refrigerant
- Precision Inverter Technology
- Window or thru-the-wall installation (window installation kit included)
Product Highlights
This Friedrich Kuhl series air conditioner features a variable speed compressor, saving energy and reducing wear and tear. It connects with the FriedrichLink App for customized control.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: KCVL28B30A
Technical Specifications
-
Installation Type: Window
-
Chassis Type: Slide-Out
-
Window Type: Standard
-
Window Mounting Kit Included: Yes
-
Refrigerant Type: R32
-
Compressor Type: Inverter
-
Energy Star: Yes
-
Dehumidification (pts/hr): 11.1
-
CFMs: 600
-
Includes Heat Mode: No
-
Cooling BTUs (@230V): 28900
-
EER2 (@230V): 10.3
-
CEER (@230V): 13.2
-
Cooling Amps (@230V): 14.3
-
Cooling Watts (@230V): 1577
-
Vent Location: Front Top
-
Make-Up Air: No
-
Energy Saver Mode: Yes
-
Fan Speeds: 4
-
Control Type: Digital
-
Filter Access: Hinged door for easy maintenance
-
Connectivity: Built-In WiFi
-
24 Hour ON/OFF Timer: Yes
-
Remote Control: Yes
-
Fresh Air Intake: Yes
-
Sleep Mode: Yes
-
Width (in.): 28
-
Depth (in.): 35.5
-
Height (in.): 20.188
-
Window Width (Min.)(in.): 29.875
-
Window Width (Max.)(in.): 42
-
In-Wall Installation Height (in.): 20.375
-
In-Wall Installation Width (in.): 28.25
-
Certifications: AHAM, UL, CUL
-
Voltage: 208-230V
-
Plug Face: 6-30
-
Circuit Breaker Size (Amps): 30
-
Cord Length: 6'
-
BTU: 28,000 BTU
-
Remote Included?: Yes
-
Heat: No
-
Series: Kuhl
-
Volts: 230 Volts
-
Amps: 14.3 Amps
-
Plug Type: 6-30P
-
Energy Star Rated: Yes
-
EER: 10.3
-
ADA Compliant: No
-
Maximum Cooling Watts: 1,577 Watts
-
Maximum Cooling Amps: 14.3 Amps
-
Type: Window / Wall
-
Energy Efficiency Rating: 10.3
-
Remote Control Included: Yes
-
Refrigerant: R32
-
Vent CFM: 600 CFM
-
Smart: App Integration
-
Cooling Capacity (BTU): 28,000 BTU
-
Net Weight: 155 lb
-
CFM: 600
-
Moisture Removal Pints: 11.1
-
Cooling Watts: 1577
-
Cooling Amps: 14.3
-
Low Cooling BTU: 14,000
-
Cooling BTU: 28,000
-
Model: KCVL28B30A
-
Circuit Rating Breaker: 250V-30A
-
Casement Window: None
-
Cooling Capacity (Btu/hr): 28900
-
Voltage (volts): 230
-
Product Class: 5b. Without reverse cycle, with louvered sides, and 28,000 Btu/h or more
-
Installation Mounting Type: Does Not Straddle Window or Windowsill
-
Support Bracket: Yes
-
Variable Speed Compressor: Yes
-
Annual Energy Use (kWh/yr): 1642.0
-
Combined Energy Efficiency Ratio (CEER): 13.2
-
Percent Less Energy Use than US Federal Standard: 47
-
Connected Capable: No
-
Nominal CFM: 600
-
Moisture Removal: 11.1 pts/hr
