Friedrich FR801T0503A14UHSNAP Endeavor�� Line F-Series Furnace 50000 BTU

Product Description

The FRIEDRICH FR801T0503A14UHSNAP Endeavor�� Line F-Series furnace is designed for HVAC applications, delivering 50000 BTU. Suitable for space-constrained installations with its low-profile, 34-inch cabinet. Features a removable heat exchanger with aluminized steel construction for corrosion resistance. This furnace is ideal for residential use, providing efficient and reliable heating.

• Features PlusOne� diagnostics with a 7-segment LED for easy service.
• Equipped with PlusOne� direct spark ignition (DSI) for reliability.
• Designed with hemmed cabinet & door edges and quarter-turn door fasteners for safe, toolless access.

Product Highlights

The FRIEDRICH FR801T0503A14UHSNAP furnace offers efficient heating with easy serviceability and a compact design.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: FR801T0503A14UHSNAP

Technical Specifications

• A2L Compatible: Contingent
• AFUE: 80
• AMP: 6.1, 8
• ANSI: ANSI Z223.1
• BTU: 50000
• BTU Heat Rating: 40000 Btu/h
• Blower Type: Direct Drive
• CEC Compliant: For Sale in CA
• CFM: 1305
• Collection: Endeavor�� Line F-Series
• Communicating: Non-Communicating
• Condensing: No
• Configuration: Horizontal, Upflow
• Depth: 29-19/32
• Fan Speeds: 5
• Flue Size: 6
• Fuel Type: Propane
• Gas Valve Stages: Single-Stage
• Heat Exchanger Type: Aluminized Steel
• Height: 34
• Horsepower: 1/2 hp
• Ignition System: Direct Spark Ignition
• Length: 29-19/32
• MBH: 50
• Max Fuse Size: 15
• Phase: Single Phase
• Power Source: Gas
• UL Listed: Yes
• Volts: 115V
• Watts: 373
• Width: 14
• MPN: FR801T0503A14UHSNAP
