Friedrich FPHSR12A1C Floating Air Pro Series 12000 BTU

Product Description

The Friedrich FPHSR12A1C 12,000 BTU Floating Air Pro Series condenser is a 115 volt single zone outdoor unit featuring inverter technology for efficient cooling. It uses R454B refrigerant and is pre-charged for up to 25 ft. of line. Designed with the HVAC technician in mind, the blower wheel assembly can be removed for cleaning and service.

• Precision Inverter Technology with Variable Speed Compressor for energy efficiency
• DiamonBlue Advanced Corrosion Protection extends the life of the unit
• Operates in cooling mode at low ambient temperatures down to 5°F

Product Highlights

This Friedrich Floating Air Pro Series condenser offers efficient cooling, quiet operation, and easy maintenance.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: FPHSR12A1C

Technical Specifications

• Cooling BTUs: 12000
• Includes Heat Pump: Yes
• Heat Pump BTUs: 12000
• Outdoor Unit Noise Level (dBA): 53
• Inverter Technology: Yes
• Line Set Liquid Line: 1/4"
• Line Set Suction Line: 3/8"
• Maximum Pipe Length (ft.): 66
• Max. Height Difference (Indoor / Outdoor) (ft.): 49
• Ambient Temperature Range - Cooling: 5°F - 118°F
• Ambient Temperature Range - Heating: -13°F - 75°F
• Min. Outdoor Temp for Heat °F: -13
• Width (in.): 31.875
• Depth (in.): 11
• Height (in.): 23
• Voltage: 110-120V
• Amps: 16
• Circuit Breaker Size (Amps): 25
• Model #: FPHSR12A1C
• A2L Compatible: Yes
• Application: Heating, Cooling
• Auto Switching Heat: Yes
• BTU: 12000
• BTU Cooling Rating: 12000 Btu/h
• HVAC System Type: Heat Pump
• Indoor Outdoor: Outdoor
• Installation Type: Wall Mount
• Proposition 65: Cancer and Reproductive Harm
• Refrigerant: R-454B
• SEER2: 22
• SEER2 Range: 15.2 - 40.0
• Type: FFPHSR12A1C
• UPC: 724587449105
• Volts: 115V
• Zones: 1
• Max. Airflow: 1,471 CFM
• Fan Motor: 36W (Output)
• Cooling Capacity: 12,000 Btu
• Heating Capacity: 12,000 Btu
• COP2: 4.0
• EER2: 12.3
• HSPF2: 9.5
• Sound Level: 53 dB(A)
• Connection: Flare
• Moisture Removal: 2.5 pints/hr
