Friedrich FPHFW18A3B Floating Air Pro Flex Single and Multi Zone Split System Heat Pump, 18000 Btu

Product Description

The FRIEDRICH FPHFW18A3B Floating Air Pro flex single and multi zone split system heat pump is designed for HVAC technicians. This unit extends versatility to condition up to four independent zones, creating room-by-room comfort with individually controlled indoor options, including built-in Wi-Fi with voice control.

• Equipped with a variable speed compressor for increased energy efficiency and minimized noise.
• Features Fast Pro design for easy blower wheel assembly removal, cleaning, and service.
• Operates at low ambient temperatures, down to 5 deg F in cooling mode and -4 deg F in heating mode.

Product Highlights

This Friedrich Floating Air Pro heat pump offers flexible, efficient, and quiet operation for single or multi-zone climate control.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: FPHFW18A3B
• Country of Origin: CN

Technical Specifications

• Type: Flex Single and Multi Zone
• Series: Floating Air Pro
• Flow Rate: 382/482/565/618 cfm
• Fuse Size: 20 A
• COP Rating: 3.4
• EER Rating: 13
• HSPF Rating: 11.6
• SEER Rating: 23.3
• Sound Level: 34/37/41/45 dB
• Power Source: 208 to 230 V 1 ph 60 Hz
• Mounting Type: Wall
• Compressor Type: Inverter
• Domestic/Import: Import
• Cooling Capacity: 6500 to 19500 Btu
• Heating Capacity: 6500 to 20000 Btu
• Nominal Capacity: 18000 Btu Cooling/19000 Btu Heating
• Refrigerant Type: R-410A
• Suction Line Size: 1/2 in
• Temperature Rating: 5 to 115 deg F Cooling/-4 to 75 deg F Heating
• Discharge Line Size: 1/4 in
• Maximum Piping Length: 66 ft
• MPN: FPHFW18A3B
• Amps Cooling: 6.3
• BtuH Cooling: 18,000
• BtuH Heating: 19,000
• CFM High: 618
• Depth: 10"
• Height: 13-1/8"
• Liquid Conn.: 1/4"
• Max. Fuse Size: 20
• Volts: 230/208
• Width: 45-1/8"
• Hz: 60 Hz
• Amps: 6.3 A
• Phase: 1
• Voltage: 208/230V AC
• Air Flow: 382/482/565/618 cfm
• Requires: Power and Communication Cable, Refrigerant Line Set for New Installation
• Standards: AHRI, ETL
• Control Type: Electronic
• For Use With: Multi Zone Outdoor Units
• Product Type: Split System Air Handler with Heat Pump
• Heating Watts: 1,638 W
• Outdoor Depth: 12 1/4 in
• Outdoor Width: 33 7/8 in
• Heating Method: Heat Pump
• Outdoor Height: 26 3/8 in
• Control Voltage: 12V DC
• Liquid Line Size: 1/4 in
• Number of Speeds: 4
• Indoor Head Depth: 9 1/4 in
• Indoor Head Width: 48 in
• Indoor Head Height: 13 in
• Indoor Sound Level: 45/41/37 dBA
• Smart Connectivity: WiFi Control
• Outdoor Sound Level: Not Rated
• Indoor Head Mounting: Wall-Mount
• Dehumidification Rate: 4.2 pt/hr
• Operation Mode - HVAC: Cooling/Heating
• Refrigerant Precharge: 25 oz
• Programming Capability: Daily Schedules
• Remote Control Functions: Full Function
• Max. Time Delay Fuse Amps: 30 A
• Max. Vertical Line Length: 49 ft
• Heating Capacity - Electric: 19,000 BtuH
• Heating Capacity - Heat Pump: 19,000 BtuH
• Seacoast Corrosion Protection: Front and Rear Coil
• Max. Line Length - Total System: 66 ft
• Number Of Indoor Units Supported: 1.0
• Min./Max. Line Length - Single Run: 28 ft
• Country of Origin (subject to change): China
• Green Certification or Other Recognition: ENERGY STAR(R) Certified
• Manufacturer Name: Friedrich Air Conditioning
• System #: FPHW183A
• System Flex: Y
• Unit Type: Indoor
• Wifi Enabled: Y
• Zone Type: Single or Multi-Zone
