Friedrich FAHMW07A3D Floating Air Pro-X Multi-Zone Indoor Wall Unit - 7000 BTU

Product Description

The Friedrich FAHMW07A3D is a 7,000 BTU indoor wall unit compatible with Friedrich multi-zone systems. This Floating Air Pro Series wall unit features FastPro Technology for easy installation and maintenance. It offers cooling operation to 5°F and heating operation down to -13°F, plus built-in WiFi and access to the Friedrich ComfortPro App. The unit also features 4-way air swing for optimized airflow.

• Built-In WiFi
• Fast Pro design for the fastest access for maintenance of any wall-mounted ductless system
• Auto Clean indoor coil

Product Highlights

The FAHMW07A3D offers customized comfort with high energy efficiencies and quiet operation. Control the unit with a smartphone, wireless remote, or voice command.

Product Information

Standard Information

• Brand: FRIEDRICH
• Manufacturer Part Number: FAHMW07A3D

Technical Specifications

• Indoor Unit Type: Wall Mount
• Cooling BTUs: 7000
• Includes Heat Pump: Yes
• Heat Pump BTUs: 7000
• Dehumidification (pts/hr): 1.9
• CFMs: 247 / 294 / 341 / 382 (L / M / H / Max)
• Fan Speeds: 4
• Min. Indoor Noise Level (dBA): 32
• Indoor Noise Level (dBA): 42/39/37/35/32 dBA (Max./H/M/L/ Quiet)
• Control Type: Hand Held Remote
• Connectivity: Built-In WiFi
• Wired Thermostat Optional: Yes
• Line Set Liquid Line: 1/4"
• Line Set Suction Line: 3/8"
• Width (in.): 33.875
• Depth (in.): 8.5
• Height (in.): 11.25
• Voltage: 208V/230V~,60Hz,1P
• Max. Airflow: 382 CFM
• Min. Airflow: 247 CFM
• Fan Motor: 25W (Output)
• Cooling Capacity: 7,000 Btu
• Heating Capacity: 7,000 Btu
• Sound Level: 42/39/37/35/32 dBA (Max./H/M/L/ Quiet)
• Connection: Flare
• Moisture Removal: 1.9 pints/hr
• A2L Compatible: Yes
• Application: Heating, Cooling
• HVAC System Type: Heat Pump
• Indoor Outdoor: Indoor
• Installation Type: Wall Mount
• Liquid Line (OD): 1/4
• Refrigerant: R-454B
• Volts: 208/230V
• Tonnage: 0.58
• Cooling Capacity (BtuH): 7000
• Heating Capacity (BtuH): 7000
• Number of HVAC Zones: 1
