Product Description
The Friedrich CCW18B30B is an air conditioner with a slide-out chassis. This 230V AC unit has a cooling capacity of 18000 BTU/Hour and a power rating of 1525 Watts. It features built-in Wi-Fi for control via the FriedrichGo App and is compatible with smart home/voice command devices. The unit has a washable, antimicrobial air filter and offers 8-way air flow control.
- Features built-in Wi-Fi control via the FriedrichGo App
- Offers smart home/voice command device compatibility
- Equipped with a slide-out chassis for easy maintenance
Product Highlights
This Friedrich air conditioner provides efficient cooling with smart features and a user-friendly design.
Product Information
Standard Information
-
Brand: FRIEDRICH
-
Manufacturer Part Number: CCW18B30B
-
Country of Origin: China
Technical Specifications
-
Cooling Capacity: 18000 BTU/Hour
-
Voltage Rating: 230 Volt
-
Current Rating: 7.1 Amp
-
Power Rating: 1525 Watt
-
Approval: UL (Canada and US)
-
Refrigerant Type: R-410A
-
Airflow Rating: 520 CFM
-
Energy Efficiency Ratio (EER): 11.9 EER
-
Combined Energy Efficiency Ratio (CEER): 11.8 CEER
-
Circuit Breaker Rating: 250 Volt, 20 Amp
-
Power Cord Length: 4 Foot
-
Brand: Friedrich
-
CATALOG NUMBER: CCW18B30B
-
Category: HVAC/R & Fans
-
Manufacturer Name: Friedrich
-
Manufacturer Part Number: CCW18B30A
-
Series: CCW
-
Type: Slide Out Chasis
-
UNSPSC Code: 40101701
-
CFM: 520 CFM
-
Hertz: 60 Hz
-
Phase: 1
-
Voltage: 230 V
-
Controls: Electronic
-
Filter Type: Washable Air Filter
-
Height: 18 in
-
Amps Cooling: 7.1 A
-
Watts Cooling: 1525 W
-
Remote Control: Yes
-
Power Cord Type: NEMA 6-20P
-
Dehumidification: 2.7
-
Number of Speeds: 3
-
Assembly Required: No
-
Country of Origin: China
-
Coverage Area: 1000 ft²
-
Manufacturers Part Number: CCW18B30B
-
Temperature Range Cooling: 60° to 115° °F
-
Certifications: UL, cUL Listed
-
Depth: 25-3/8 in
-
Width: 23-5/8 in
-
Item: Window Air Conditioner
-
Watts: 1,525
-
Includes: Window Installation Hardware
-
Standards: cULus Listed
-
Duty Rating: Residential Grade
-
Chassis Type: Slide Out
-
For Use With: Window Installation Only
-
Heating Method: Not Applicable
-
Fits Window Type: Double Hung, Slider
-
Min. Window Width: 26 in
-
Air Flow Direction: 8 Way
-
Min. Window Height: 16 in
-
Smart Connectivity: WiFi Control
-
Voltage - Plug Type: 230V AC - 6-20P
-
Operation Mode - HVAC: Cooling Only
-
Overall Dimensions H x W x D: 18 in x 23 5/8 in x 25 3/8 in
-
NEMA Plug Configuration - HVAC: 6-20P
-
Country of Origin (subject to change): China
-
Model: CCW18B30B
-
Energy Star Qualified: Y
-
Operation: Cool Only
-
Cooling BTU: 18000
-
Heating BTU: ---
-
EER: 11.8
-
CEER: 11.8
-
Cooling Area (Sq Ft.): 700-1000
