Franklin Electric 2445059004GS 4" Super Stainless 1/2 HP 230V 2-Wire Submersible Well Motor

Product Description

The Franklin Electric 2445059004GS 4-inch Super Stainless submersible motor is designed for dependable residential and light commercial water well applications. Built with Franklin’s proven Super Stainless construction, this 1/2 HP motor delivers reliable performance in 4-inch diameter or larger water wells.

This single-phase, 2-wire motor operates at 230V and 60 Hz and is engineered for continuous duty. Featuring stainless steel construction, a Kingsbury-type thrust bearing, and IP68 protection, it provides long-lasting durability in demanding groundwater environments.

The motor is factory-filled with a non-toxic water and propylene glycol solution and is designed for clean groundwater applications.

Product Highlights

• 1/2 HP submersible well motor (60 Hz)
• 230 VAC, Single-Phase, 2-Wire configuration
• Super Stainless motor construction
• Continuous duty rated
• IP68 protected
• 300 lb thrust bearing rating
• UL listed
• ANSI/NSF Standard 61 approved for drinking water
• Designed for 4" diameter or larger water wells

Technical Specifications

• Horsepower (HP): 1/2 HP
• Frequency: 60 Hz
• Phase: Single-Phase
• Voltage: 230 VAC
• Voltage Tolerance: -10% / +10%
• Full Load Amps: 5 A
• Service Factor Amps: 6 A
• Service Factor (S.F.): 1.6
• Poles: 2
• Motor Insulation Class: B

Dimensions & Weight

• Motor Diameter: 3.75"
• Motor Length: 9.51"
• Shaft Diameter: 0.61"
• Product Weight (with packaging): 18 lb

Carton Dimensions

• Length: 19"
• Width: 4.25"
• Height: 4.38"
