Ford Meter Box FB500-3-NL 3/4 in. MIPS Brass Ball Corp Valve

Product Description

The FORD METER BOX FB500-3-NL is a 3/4 in. MIPS Brass Ball Corp Valve. Ford recommends using insert stiffeners with plastic pipe or tubing. Ends are integral or secured with adhesive to prevent unintentional disassembly. Requires Certification.

• Lead Law Compliant
• ASTM B62, ASTM B584
• AWWA C800

Product Highlights

This brass ball valve features MPT end connections, is lead law compliant, and certified to NSF 61 and NSF 372.

Product Information

Standard Information

• Brand: FORD METER BOX
• Manufacturer Part Number: FB500-3-NL

Technical Specifications

• ASTM: ASTM B62, ASTM B584
• AWWA: AWWA C800
• End Connection 1: MPT
• End Connection 2: MPT
• End Connections: MPT
• Inlet Service Size: 3/4
• Lead Law Compliance Level: Lead Law Compliant and Certified
• Lead Law Compliant: Yes
• Length: 4-15/64
• Material: Brass
• NSF: NSF 61, NSF 372
• NSF Certified: Yes
• OutletMeter Size: 3/4
• Pressure - Maximum: 300 psi
• Pressure Class: 300#
• Valve Size: 3/4 in
• Weight: 1.4
