Ford Meter Box b41-444m-q-nl 1 in Ball Valve Cts Qj X Fip

Product Description

The FORD METER BOX b41-444m-q-nl is a 1-inch no-lead ball valve designed for water service applications requiring a CTS Quick Joint inlet and a 1-inch Female Iron Pipe Thread (FIP) outlet. This valve meets Minneapolis-style no-lead compliance standards, making it suitable for potable water systems. The ball valve design provides full-bore shutoff capability with a quarter-turn operation. At 3 pounds, it is a solid, service-grade valve appropriate for residential and light commercial water service installations. Licensed plumbers and water service contractors are the primary installers of this type of fitting.

This valve is used in water service line applications where CTS (Copper Tube Size) pipe connects to a FIP threaded fitting. The Quick Joint end allows for tool-assisted push-fit connection to CTS tubing, while the female iron pipe thread end connects to threaded iron or brass fittings. Typical installation scenarios include new water service taps, meter set assemblies, and service line repairs where a shutoff valve is required between the main and the meter or downstream piping.

Key Features

• No-lead construction for potable water compliance
• 1-inch CTS Quick Joint inlet for push-fit connection to copper tube size pipe
• 1-inch Female Iron Pipe Thread outlet for threaded fitting connections
• Quarter-turn ball valve design for positive full-bore shutoff
• Minneapolis-style compliance configuration

Compatibility

Designed for use in potable water service line assemblies using 1-inch CTS tubing on the supply side and 1-inch FIP threaded connections on the downstream side. No additional compatible model numbers were specified in the product data.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and applicable IPC requirements. Shut off the water main and relieve system pressure before connecting or removing any fittings. The Quick Joint end requires proper CTS tubing preparation including deburring and squaring the cut end before seating. Do not over-tighten the FIP threaded connection; use appropriate thread sealant or tape rated for potable water service.

Technical Specifications

• Size: 1 inch
• End Connections: CTS Quick Joint x Female Iron Pipe Thread
• Lead Compliance: No Lead
• Weight: 3 pounds

Standard Information

• Brand: FORD METER BOX
• Manufacturer Part Number: b41-444m-q-nl
