Product Description
The Flexcon PH5 is a wall-hung expansion tank designed for use in gas or electric direct-fired residential water heaters and hot water storage tanks. With a tank capacity of two point one gallons and a maximum working pressure of one hundred fifty pounds per square inch, it is suitable for various heating applications.
- Tank capacity of two point one gallons
- Inlet and outlet connection of three fourths inch male NPT
- Built with a durable copper lined steel body
Product Highlights
This expansion tank features a butyl rubber diaphragm that separates the system water from the air precharge, enhancing its longevity. The unit is designed to handle high pressure and ensures the integrity of your water heating system.
Product Information
Standard Information
-
Brand: Flexcon
-
Manufacturer: Flexcon
Technical Specifications
-
Type: Wall Hung
-
Tank Capacity: 2.1 gallons
-
Pressure Rating: 150 PSI
-
Inlet/Outlet Connection: 3/4 inch Male NPT
-
Precharge Pressure: 20 PSI
-
Diaphragm Material: Butyl Rubber
-
Material: Copper Lined Steel
-
Application: Direct fired residential water heater and hot water storage tank
-
Shipping Weight: 5 pounds
