FIRSTCO LMS-AH11 Heat/Cool Thermostat

Product Description

The FIRSTCO LMS-AH11 is a solid-state thermostat designed for low voltage single-stage systems. It is suitable for commercial and industrial installations that require accurate temperature control. This thermostat is built with a locking case that needs a special key for access, offering tamper resistance. It also adheres to industry standards for wiring and terminal identification. Ideal for use in fast food restaurants, churches, schools, and retail environments. This model ensures precise temperature management without the need for leveling or anticipator adjustments.

• Locking case with special key required for access
• Installation uses the same wiring as a bi-metal thermostat
• Accurate temperature control without additional adjustments

Product Highlights

The FIRSTCO LMS-AH11 ensures reliable performance in various environments, enhancing temperature management capabilities.

Product Information

Standard Information

• Country of Origin:
• UPC:

Technical Specifications

• Voltage: 18-26 VAC
• Sensing: Preset or Adjustable Sensors
• Rating: 1.2 Amps per stage
• Stages: 1H/1C
• Temperature Adjustable: High or Low
• Differential: Approx. 2° F
• Case: Plastic, White
• Wire Connection: Screw Terminal
• Dimensions: 4.6 inches W x 4.6 inches H x 1.5 inches D
