First Company 30HXS1002UAP000AAF 2.5 Ton R410A Fan Coil Unit With 10 KW

Product Description

The First Co. 30HXS1002UAP000AAF is a 2.5 ton R410A fan coil unit equipped with a patented 10 kW electric heater. This model functions efficiently at 208/240 volts and utilizes a PSC motor. It is suitable for both ceiling and fur-down installations. It provides an airflow of one thousand CFM and is designed to work with R22 or R410A refrigerants.

• Factory-installed 10 kW electric heater
• Compatible with R22 and R410A refrigerants
• Airflow capacity of 1000 CFM

Product Highlights

This fan coil unit is built to deliver reliable heating and cooling in various applications, making it ideal for residential and commercial settings.

Product Information

Standard Information

• MFG#: 30HXS1002UAP000AAF
• UPC: 850046856907

Technical Specifications

• Ton: 2.5
• Liquid Line Size: 3/8 inches
• Suction Line Size: 7/8 inches
• Heat: 10 kW
• CFM: 1000
• Type: Fur Down
• Refrigerant Type: R22/R410A
• Cooling Capacity: 30000 BTU
• Voltage: 208/240 V
• Wattage: 10 kW
• Amperage: 43.6 amp
• Maximum Fuse Amperage: 60 amp
• Package Quantity: 1
