Fireye MEP437 Programmer, Valve Proof of Closure, Selectable Purge

Product Description

The Fireye MEP437 is a programmer designed for valve proof of closure in burner management systems. It ensures safe operation by managing the ignition process and flame monitoring effectively. This module is suitable for various heating applications and is customizable to fit specific process requirements.

• Operating temperature range from negative forty degrees Fahrenheit to one hundred forty degrees Fahrenheit.
• User-selectable purge times from zero to two hundred forty seconds.
• Lockout action on flame fail during the ignition period.

Product Highlights

The MEP437 provides reliable flame safeguard control using a microprocessor-based system. It enables automatic ignition and verifies flame presence, ensuring that all ignition conditions are met before proceeding.

Product Information

Standard Information

• Brand: Fireye
• Part Number: MEP437

Technical Specifications

• Operating Temperature: -40 F to 140 F
• Operating Limit Input: Terminal 6
• Post Purge Time: 15 seconds after operating limit opens with flame present
• Pilot Trial For Ignition Period: User selectable 5 or 10 seconds
• Purge Time: User selectable from 0 to 240 seconds
• Main Trial For Ignition Period: 5 second
• Microprocessor Control: Zero dependence on discrete components for timing functions
