Firestone W013587484 Single Convolute Airstroke Actuator Airmount Isolator

Product Description

Firestone W013587484 is a single convolute airstroke actuator designed to provide effective motion control and vibration isolation. This air spring performs well in industrial applications, offering a low profile compared to traditional air cylinders. Its flexible design makes it suitable for equipment such as presses, conveyors, lifts, and packaging machines.

• Provides linear or angular motion
• Effective vibration isolation
• Suitable for various industrial applications

Product Highlights

This actuator features a two-ply, fabric-reinforced rubber construction, allowing for significant flexibility while maintaining strength.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587484

Technical Specifications

• Stroke Length [Max]: 3 inches
• Air Inlet Type: NPT
• Force @ 3 in Stroke: 1288 lbf
• Pressure [Max]: 100 psi
• Compressed Height: 2.1 inches
• Temperature Range [Min]: -35 °F
• Temperature Range [Max]: 135 °F
• Bellows Type: Single Convolution
