Firestone W013587431 Double Convolute Airstroke Actuator/Airmount Isolator

Product Description

The Firestone W013587431 is a double convolute airstroke actuator and airmount isolator designed for industrial applications. This air spring offers both actuator and isolator functionalities. It provides effective linear and angular motion in a compact profile compared to traditional air cylinders.

• High flexibility suited for various machine operations.
• Reduces vibration effects in pressing, lifting, and packaging machines.
• Constructed from two-ply, fabric-reinforced rubber.

Product Highlights

This product is widely used in industrial applications requiring precise motion control and vibration mitigation.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587431

Technical Specifications

• Style No.: 22
• Convolutions: Double
• Stroke Length (Max): 6.900 inches
• No. of Bolts: 12
• Pressure (Max): 100 psi
• Compressed Height: 3.2 inches
• Force @ 1 in Stroke: 8975 lbf
• Force @ 3 in Stroke: 8088 lbf
• Force @ Maximum Stroke (100 psi): 4625 lbf
• Temperature Range (Min): -35 °F
• Temperature Range (Max): 135 °F
• Air Inlet Type: NPT
• Bolt Circle Diameter: 9 inches
• Weight: 11.5 lb
• EAN or UPC: 767555004784
