Firestone W013587325 Double Convolute Airstroke Actuator Airmount Isolator

Product Description

The Firestone W013587325 is a double convolute airstroke actuator and airmount isolator designed for industrial applications. It offers both actuator and isolator functions efficiently in small spaces. This product is suitable for machines that require motion and vibration isolation.

• Two-ply, fabric-reinforced construction
• Flexible media for various applications
• Ideal for vibration-sensitive equipment

Product Highlights

The Firestone air springs effectively reduce vibration while providing linear or angular motion. Their durable structure enhances functionality in pressing, conveying, and lifting tasks.

Product Information

Standard Information

• Brand: Firestone
• MPN: W013587325

Technical Specifications

• Force @ Stroke (100 psi): 3437.5 lbf @ 1 in, 3287.5 lbf @ 3 in
• Air Inlet: 1/4 in
• Pressure [Max]: 100 psi
• Stroke Length [Max]: 5.700 in
• Compressed Height: 2.8 in
• Temperature Range [Min]: -35 °F
• Temperature Range [Max]: 135 °F
• Weight: 5.3 LB
